SIPLACE 80S-20/F4/F4-6/F5 User’s Manual 0 Introduction Edition 03/98 from S oftware Version SR.404.xx 0.2 Technical Data 0 - 11 0.2.1.5 Machine Dime nsions 0.2.1. 6 Permi ssibl e Environme ntal Infl uences 0.2.1.7 Machin…

100%1 / 744
0 Introduction SIPLACE 80S-20/F4/F4-6/F5 User’s Manual
0.2 Technical Data Edition 03/98 from Software Version SR.404.xx
0 - 10
0.2.1.3 Boards, Components, Tapes
0.2.1.4 Connection and Installation Data
Boards, components, tapes
Boards (PCB) transport system In-line transport with width adjustment
PCB format
50 mm x 50 mm to 460 mm x 460 mm with PCB buffer
50 mm x 50 mm to 508 mm x 460 mm without PCB buffer
(upon request)
Component-free guide edge of the
board
3 mm
Min. PCB thickness 0.5 mm
Max. PCB thickness 4.5 mm
Max. PCB warpage Upwards : 4.5 mm less PCB thickness
Downwards: 0.5 mm plus PCB thickness
PCB change time 2.5 sec.
Max. number of 8 mm tapes 80
Tape reel diameter Max. 15“ in the reel container
Connection and installation data
System voltage 230/400 V ± 10 % (50/60 Hz.)
System voltage (Option for USA) 110/208 V ± 10 % (50/60 Hz.)
Total connected load 5 kVA
Total power consumption 5 kW
Fuse protection 3 x 16 A
Compressed air supply Min. 5.5 bar / max. 10 bar
Entire compressed air consumption 400 NL/min.
Machine footprint
Permissible surface load > 1000kg/m
2
SIPLACE 80S-20/F4/F4-6/F5 User’s Manual 0 Introduction
Edition 03/98 from Software Version SR.404.xx 0.2 Technical Data
0 - 11
0.2.1.5 Machine Dimensions
0.2.1.6 Permissible Environmental Influences
0.2.1.7 Machine Control
Machine dimensions
Weight base module 1500 kg
Weight fully-equipped ca. 2000 kg
Length 1587 mm
Width 2425 mm
Height with warning light 1836 mm
Permissible environmental influences
Room temperature
Between 15
o
C and 35
o
C
Air humidity
30 to 75 %
(on average not higher than 45 % so that under no circum-
stances will there be condensation in or on the machine.)
Machine control
Computer
machine controller
PC 486
RMOS operating system
Computer
station control
Pentium PC
MS-Windows NT 4.0 operating system
Machine control Siemens S5 input/output control
Axis controller Siemens axis controller boards (digital)
0 Introduction SIPLACE 80S-20/F4/F4-6/F5 User’s Manual
0.2 Technical Data Edition 03/98 from Software Version SR.404.xx
0 - 12
0.2.1.8 Compressed Air Specification
0.2.1.9 Noise Emission Values
Compressed air specification
Max.partical size by density, based on ISO/DIS 8573-1 (Class 1)
Particle size 0.1 µm
Particle density
0.1 mg/m
3
Max. oil content (Class 1)
Particle density 0.01 mg/m
3
Pressure dewpoint (Class 4)
Dewpoint +3
o
Noise emission values specified in accordance with DIN 45 649-1
Emission value at a workstation (L
pAc
) 71 dB (A)
DIN EN ISO 11204 (i)
Sound power level (L
WAc
) 85 dB (A)
E-DIN EN ISO 3744 (i)
