9 Maintenance SIPLACE 80S-20/F4/F4-6/F5 User’s Manual
9.2 Maintenance Schedules Edition 03/98 from Software Version SR.404.xx
9 - 14
9.2.2 Additional Maintenance for the SIPLACE 80F
4
/F
4
-6/F
5
Placement
Machines
Module Subassembly
To be carried out weekly
(15 / 17 shifts )
Equipment
Date
done
Wafflepack
changer
LZ60 coarse filter Vacuum clean Vacuum cleaner
IC head
Friction wheel at the
motor of the d axis
Clean
Ethyl alcohol,
lint-free cloth
O-ring of pick-up star
Clean groove, check and service
sealing ring, if necessary replacing
Ethyl alcohol,
Unisilkon L250L
Tab. 9.2.9 Additional maintenance for the SIPLACE 80F
4
/F
4
-6/F
5
: To be carried out weekly
Module Subassembly
To be carried out every month
(60 / 70 shifts)
Equipment
Date
done
IC head
IC head nozzles,
diaphragm
Apply a small amount of talcum with
a cloth
Talcum,
lint-free cloth
Sleeve Oil sleeve Watchmaker’s oil
Encoder disk Clean Lens cleaning cloth
Cover Check for contamination
Ethyl alcohol,
lint-free cloth
Tab. 9.2.10 Additional maintenance for the SIPLACE 80F
4
/80F
4
-6/F
5
: To be carried out every month (60 / 70 shifts)
Module Subassembly
To be carried out every 8 months
(480 / 560 shifts)
Equipment
Date
done
Wafflepack
changer
Recirculating ball screws
linear guides
Clean, grease
(lubrication nipple)
Grease gun,
Urethyn E/M2
Tab. 9.2.11 Additional maintenance for the SIPLACE 80F
4
/80F
4
-6/F
5
: To be carried out every 8 months (480/560 shifts)
Module Subassembly To be carried out as required Equipment
Date
done
IC head
Silencer
Inspect, replace if necessary;
from item no. 00308498-01
Vacuum nozzle
O-rings
Clean, inspect, grease
Ethyl alcohol,
Unisilkon L205L
IC camera
Clean reflective surfaces and
glass disk
Soft, grease-free
brush, cloth for
cleaning optical
equipment
Tab. 9.2.12 Additional maintenance for the SIPLACE 80F
4
/80F
4
-6/F
5
: To be carried out as required
SIPLACE 80S-20/F4/F4-6/F5 User’s Manual 9 Maintenance
Edition 03/98 from Software Version SR.404.xx 9.2 Maintenance Schedules
9 - 15
9.2.3 Additional Maintenance for the SIPLACE 80F
5
Placement
Machine
FC camera
Clean reflective surfaces and
glass disk
Soft, grease-free
brush, cloth for
cleaning optical
equipment
Coplanarity
module
Clean glass disk
Soft, grease-free
brush, cloth for
cleaning optical
equipment
Waffle-pack
changer
Guide rails and tray stor-
age unit
Remove abrasion deposits Damp, lint-free cloth
Module Subassembly
To be carried out weekly
(15/17 shifts)
Equipment
Date
done
Empty tape
cutter for 80F
5
Cutter blade Vacuum clean Vacuum cleaner
Tab. 9.2.13 Additional maintenance for the SIPLACE 80F
5
: To be carried out weekly
Module Subassembly
To be carried out monthly
(60/70 shifts)
Equipment
Date
done
Empty tape
cutter for 80F
5
Moving
cutter blade
Apply lubricant and corrosion
inhibiting agent to the sliding sur-
face between the moving cutter
blade and the retainer
WD-40
Tab. 9.2.14 Additional maintenance for the SIPLACE 80F
5
: To be carried out monthly
Module Subassembly To be carried out as required Equipment
Date
done
Empty tape
cutter for 80F
5
Cutter blade
Change the cutting edges or replace
the cutter blade
Hexagon socket
screw key
Tab. 9.2.15 Additional maintenance for the SIPLACE 80F
5
: To be carried out as required
Module Subassembly To be carried out as required Equipment
Date
done
Tab. 9.2.12 Additional maintenance for the SIPLACE 80F
4
/80F
4
-6/F
5
: To be carried out as required
9 Maintenance SIPLACE 80S-20/F4/F4-6/F5 User’s Manual
9.2 Maintenance Schedules Edition 03/98 from Software Version SR.404.xx
9 - 16
