11.8.4 Possible Functions
The following components can be accessed remotely from the service centers in Munich, Singapore and
Alpharetta and the corresponding functions operated and monitored.
l Line computer (SCO UNIX)
- Remote log-in
- Chat
- Sending commands to the customer‘s line computer
- Starting and stopping programs in the customer‘s line computer
- Remote editing
- File transfer
l Station computer
- Remote log-in
- Remote operation of programs (user interface, diagnostics)
- Remote operation of customer‘s user interface
- Remote display of customer‘s user interface
- Sending messages to customer‘s station computer (chat mode)
- File transfer
- Remote editing
- Logging
l Machine controller (RMOS 3.20)
- Remote log-in
- File transfer
11 Station Extensions/Options SIPLACE 80S-20/F4/F4-6/F5 User’s Manual
11.8 Remote Service Edition 03/98 from Software Version SR.404.xx
11 - 56
11.8.5 Overview
The following possibilities as regards configuration are available to the customer‘s placement line:
Connection of the ISDN router to the local SIPLACE LAN and connection of the ISDN router to customer‘s site
LAN.
11.8.5.1 Connecting the ISDN Router to the Local SIPLACE LAN
This possibility is used when there is no local LAN available at the customer. The customer will not need to
implement any additional data security measures.
Fig. 11.8.1 Connection to local SIPLACE LAN
Line computer
Router
Station com-
puter
Machine
controller
SIPLACE
LAN
Router
Station com-
puter
LAN
Line computer
Customer‘s placement line Service center
ISDN
network
= LAN card
SIPLACE 80S-20/F4/F4-6/F5 User’s Manual 11 Station Extensions/Options
Edition 03/98 from Software Version SR.404.xx 11.8 Remote Service
11 - 57
11.8.5.2 Connecting the ISDN Router to the Customer‘s Site LAN
The advantage of this alternative is that several placement lines can be addressed via a single router.
Fig. 11.8.2 Connection to the customer‘s site LAN
Line computer (LC)
Router
Station com-
puter
Machine
controller
SIPLACE
LAN
Router
Station com-
puter
LAN
Line computer(LC)
Service center
Customer‘s central site network
= LAN card
ISDN
network
Customer‘s placement line
