KL T -1506 19 24 10 40 27 18 34 1 6 29 15 26 2 5 37 25 11 16 15 1 18 40 39 14 21 39 12 41 42 4 41 44 43 23 4 13 20 22 7 35 30 5 37 8 5 37 2 5 28 17 9 4 5 31 30 35 33 32 37 37 5 5 5 36 8 36 4 37 3 5 28 9 31 32 36 37 5 4 3…
KLT-1506
Rev. :It had a change without the compatibility. Please be careful at the time of the parts ordering.
Rev.: 過去に互換性の無い変更が入った部品。部品発注時は注意してください。
No. Part No. Part Name Q’ty Remarks Rev. Rank Level No. Part No. Part Name Q’ty Remarks Rev. Rank Level
1 90990-01J032 BOLT HEX,SOCKET HEAD 8 39 KHN-M22F8-00 WASHER,SWR08 16
/
Í
2 90990-11J006 SCREW, PAN HEAD W/W 4 40 KHY-M22C5-00 COVER UNDER,X AXIS 1
/
3 90K65-612F03 AC SERVO MOTOR 1 B
Í
41 KLT-M2213-S2 PLATE X AXIS SET 1
/
Í
4 90990-11J007 BOLT HEX,SOCKET HEAD 2 42 KV7-M2231-00 SPACER R,NUT 4
/
Í
5 91312-04006 BOLT HEX,SOCKET HEAD 8 43
6 91312-05008 BOLT HEX,SOCKET HEAD 12 44
7 91312-06010 BOLT HEX,SOCKET HEAD 4 45
8 91312-06020 BOLT HEX,SOCKET HEAD 4 46
9 97602-03310
SCREW PAN HEAD W/WASHER
6 47
10 98902-03006 SCREW BINDING HEAD 4 48
11 98902-04006 SCREW BINDING HEAD 4 49
12 KGT-M2266-10 PLATE, NUT 2 /
Í
50
13 KHY-M227G-00 COVER,B.S. 1 /
51
14 KKX-M6555-00 JUNCTION BOX V 1 /
Í
52
15 KLT-M220A-00 TAPE,X DUCT 1 1 /
Í
53
16 KLT-M220B-00 TAPE,X DUCT 2 1 /
Í
54
17 KLT-M220C-00 TAPE,X DUCT 3 1 /
Í
55
18 KLT-M220D-00 TAPE,X AXIS 1 1 /
Í
56
19 KLT-M220E-00 TAPE,X AXIS 2 1 /
Í
57
20 KLT-M221A-A0 COVER DUCT ASSY. 1 /
Í
58
21 KLT-M2223-00 BRACKET,DUCT 1 /
Í
59
22 KLT-M223A-00 STAY,DUCT 1 /
Í
60
23 KLT-M2267-A0 X DUCT ASSY. 1 B
Í
61
24 KLT-M223H-00 STAY,HNS. 1 /
Í
62
25 KLT-M2268-01 BRACKET,TAPE 1 1 /
Í
63
26 KLT-M2269-01 BRACKET,TAPE 2 1 /
Í
64
27 KLT-M2282-00 DOG,X OT 2 /
Í
65
28 KLT-M2284-00 STAY,ORG X 1 /
Í
66
29 KLT-M2285-00 STAY,LIMIT X 1 /
Í
67
30 KLT-M22K2-00 BRACKET,K2 1 /
Í
68
31 KLT-M652A-00 SENSOR,X OT+ ASSY. 1 B
Í
69
32 KLT-M652B-00 SENSOR,X OT- ASSY. 1 B
Í
70
33 KLT-M652C-00 SENSOR,X ORG ASSY. 1 B
Í
71
34 KM0-M2220-00 COUPLING, X-AXIS 1 /
Í
72
35 KV7-M7165-00 SEAL DON'T TOUCH 2 /
73
36 KLT-M223J-00 BRKT.,HNS SENSOR 2 /
Í
74
37 90990-01J038 BOLT HEX,SOCKET HEAD 6 75
38 91312-08025 BOLT HEX,SOCKET HEAD 16 76
3
1
X-axis
Moving-axis
KLT-1506
19
24
10
40
27
18
34
1
6
29
15
26
2
5
37
25
11
16
15
1
18
40
39
14
21
39
12
41
42
4
41
44
43
23
4
13
20
22
7
35
30
5
37
8
5
37
2
5
28
17
9
4
5
31
30
35
33
32
37
37
5
5
5
36
8
36
4
37
3
5
28
9
31
32
36
37
5
4
36
3
3
2
Y-axis
Moving-axis
KLT-1506
Rev. :It had a change without the compatibility. Please be careful at the time of the parts ordering.
Rev.: 過去に互換性の無い変更が入った部品。部品発注時は注意してください。
No. Part No. Part Name Q’ty Remarks Rev. Rank Level No. Part No. Part Name Q’ty Remarks Rev. Rank Level
1 90990-01J032 BOLT HEX,SOCKET HEAD 8
40
98502-03004 SCREW PAN HEAD 4
2 90K63-611404 AC SERVO MOTOR 2 B
Í
41
98502-03008 SCREW PAN HEAD 6
3 91312-04006 BOLT HEX,SOCKET HEAD 6
42
KLT-M652D-00 SENSOR,Y OT+ ASSY. 1
B
Í
4 91312-04008 BOLT HEX,SOCKET HEAD 7
43
KLT-M652E-00 SENSOR,Y OT- ASSY. 1
B
Í
5 91312-05008 BOLT HEX,SOCKET HEAD 28
44
KLT-M652F-00 SENSOR,Y ORG ASSY. 1
B
Í
6 91312-05010 BOLT HEX,SOCKET HEAD 4
45
7 91312-06008 BOLT HEX,SOCKET HEAD 2
46
8 91312-06010 BOLT HEX,SOCKET HEAD 4
47
9 91312-06018 BOLT HEX,SOCKET HEAD 8
48
10 KGS-M2256-00 GRIP 1 /
Í
49
11 KHY-M260A-00 TAPE, Y AXIS 1 /
Í
50
12 KHY-M260B-00 TAPE,Y DUCT 1 /
Í
51
13 KHY-M260C-00 TAPE 2, Y DUCT 1 /
Í
52
14 KHY-M260D-00 TAPE 3, Y DUCT 1 /
Í
53
15 KHY-M2669-00 BRACKET,HARNESS 2 /
Í
54
16 KHY-M2678-00 GUIDE,CABLE Y 1 A
Í
55
17 KLT-M2658-00 BRKT.,FIX Y AXIS 1 /
56
18 KV7-M2266-00 PLATE, NUT 2 /
Í
57
19 KLT-M2682-00 DOG,ORIGIN 1 /
Í
58
20 KLT-M2683-00 DOG,SECOND LIMIT 1 1 /
Í
59
21 KLT-M2684-00 DOG,SECOND LIMIT 2 1 /
Í
60
22 KLT-M2685-01 STAY,DOG 1 /
Í
61
23 KLT-M2686-00 BRACKET,SENSOR 1 1 /
Í
62
24 KLT-M2687-01 BRACKET,SENSOR 2 1 /
Í
63
25 KLT-M2694-00 BRACKET,GUIDE A 1 /
Í
64
26 KLT-M2695-00 BRACKET,GUIDE Y AXIS 1 /
Í
65
27 KLT-M26C1-01 COVER,TOP BS.R 1 /
66
28 KLT-M26C2-00 COVER,BALL SCREW 1 2 /
67
29 KLT-M26C3-01 COVER,TOP BS.L 1 /
68
30 KLT-M26C4-00 COVER,BALL SCREW 3 2 /
69
31 KLT-M26C5-00 SHAFT,COVER 4 /
Í
70
32 KLT-M26C6-01 BRKT.,COVER Y AXIS 2 /
Í
71
33 KLT-M26C7-01 BRKT.,R COVER Y 1 /
Í
72
34 KLT-M26C8-01 BRKT.,L COVER Y 1 /
Í
73
35 KM0-M2220-00 COUPLING, X-AXIS 2 /
Í
74
36 92902-04200 WASHER,PLAIN 8
75
37 92902-05200 WASHER,PLAIN 20
76
39
97602-03306
SCREW PAN HEAD W/WASHER
4
77
3
2
Y-axis
Moving-axis
