KL T -1406 33 29 25 15 16 23 16 34 4 12 33 13 30 6 32 9 1 21 17 35 35 17 3 18 31 28 7 14 12 4 27 34 24 8 33 19 16 34 19 33 8 36 1 1 33 29 33 19 25 8 19 33 20 22 10 26 16 34 18 24 1 1 5 8 2 8 5 3 Transport Conveyor

100%1 / 53
KLT-1506
Rev. :It had a change without the compatibility. Please be careful at the time of the parts ordering.
Rev.: 過去に互換性の無い変更が入った部品。部品発注時は注意してください。
No. Part No. Part Name Q’ty Remarks Rev. Rank Level No. Part No. Part Name Q’ty Remarks Rev. Rank Level
1 $UEF4BU-M3 JOINT 10 39
2 90112-2AJ005 BOLT, HEX.SOCKET HEAD 10 40
3 90990-08J027 SCREW, PAN HEAD 10 41
4 91312-03030 BOLT HEX,SOCKET HEAD 10 42
5 91312-04006 BOLT HEX,SOCKET HEAD 10 43
6 91312-04010 BOLT HEX,SOCKET HEAD 20 44
7 KHW-M916C-00 SPACER 10 /
Í
45
8 KHW-M916G-00 COLLAR, JOINT 5 /
Í
46
9 KHY-M926H-00 JOINT, CYL. 5 /
Í
47
10 KKE-M9169-01 SHAFT,STOPPER 5 /
Í
48
11 KKE-M916B-00 GUIDE 5 /
Í
49
12 KLT-M9161-00 BRKT.,CYLINDER 3 /
Í
50
13 KLT-M9162-00 BRKT.,CYLINDER 2 /
Í
51
14 KLT-M9163-00 PLATE,STOPPER 2 2 /
Í
52
15 KLT-M9164-00 BRKT.,STOPPER 3 /
Í
53
16 KLT-M9165-00 PLATE,STOPPER 1 3 /
Í
54
17 91312-04012 BOLT HEX,SOCKET HEAD 5 55
18 92902-04600 WASHER,PLAIN 5 56
19 KLT-M9167-00 BRKT.,STOPPER 2 2 /
Í
57
20
KLT-M9168-00 PLATE,STOPPER 5 /
Í
58
21 KLT-M653F-01 MST.1 CYL. ASSY.,1 1
Fix. frame-Main
B
Í
59
22 KLT-M653G-00 MST.1 CYL. ASSY.,2 1
Mov. frame-Main
B
Í
60
23 KLT-M653H-00 MST.2 CYL. ASSY.,1 1
Fix. frame-Second Main
B
Í
61
24 KLT-M653J-00 MST.2 CYL. ASSY.,2 1
Mov. frame-Second Main
B
Í
62
25 KLT-M653K-01 SUB ST. CYL. ASSY. 1 Fix. frame-Sub B
Í
63
26 KLT-M9160-A0 STOPPER ASSY.,1 1
R-L Fix. frame-Main
/
Í
64
27 KLT-M9160-B0 STOPPER ASSY.,11 1
R-L Mov. frame-Main
/
Í
65
28 KLT-M9160-C0 STOPPER ASSY.,7 1
R-L Fix. frame-Second Main
/
Í
66
29 KLT-M9160-D0 STOPPER ASSY.,13 1
R-L Mov. frame-Second Main
/
Í
67
30 KLT-M9160-E0 STOPPER ASSY.,12 1
R-L Fix. frame-Sub
/
Í
68
31 KLT-M9160-F0 STOPPER ASSY.,4 1
L-R Fix. frame-Main
/
Í
69
32 KLT-M9160-G0 STOPPER ASSY.,14 1
L-R Mov. frame-Main
/
Í
70
33 KLT-M9160-H0 STOPPER ASSY.,10 1
L-R Fix. frame-Second Main
/
Í
71
34 KLT-M9160-J0 STOPPER ASSY.,16 1
L-R Mov. frame-Second Main
/
Í
72
35 KLT-M9160-K0 STOPPER ASSY.,15 1
L-R Fix. frame-Sub
/
Í
73
36 74
37 75
38 76
5
2
Stopper Assy
Conveyor
KLT-1406
33
29
25
15
16
23
16
34
4
12
33
13
30
6
32
9
1
21
17
35
35
17
3
18
31
28
7
14
12
4
27
34
24
8
33
19
16
34
19
33
8
36
11
33
29
33
19
25
8
19
33
20
22
10
26
16
34
18
24
11
5
8
2
8
5
3
Transport
Conveyor
KLT-1406
Rev. :It had a change without the compatibility. Please be careful at the time of the parts ordering.
Rev.: 過去に互換性の無い変更が入った部品。部品発注時は注意してください。
No. Part No. Part Name Q’ty Remarks Rev. Rank Level No. Part No. Part Name Q’ty Remarks Rev. Rank Level
1 90990-28J018 WASHER,PLAIN 1
39
2 90990-28J076 WASHER,PLAIN 1
40
3 90990-41J006 COLLAR 1
41
4 91312-03010 BOLT HEX,SOCKET HEAD 8
42
5 91312-04005
BOLT HEX,SOCKET HEAD 2
43
6 91312-04008
BOLT HEX,SOCKET HEAD 1
44
7 91312-04010
BOLT HEX,SOCKET HEAD 2
45
8
91312-04012 BOLT HEX,SOCKET HEAD
9
46
9 91312-04050 BOLT HEX,SOCKET HEAD 4
47
10 91312-05008 BOLT HEX,SOCKET HEAD 2
48
11 91312-05020 BOLT HEX,SOCKET HEAD 2
49
12 KG2-M9108-11 COLLAR CONVEYOR 2 /
Í
50
13 KGK-M9170-00 DC MOTOR ASSY. 1 B
51
14 KGT-M9135-00 PULLEY 1, SPLINE 1 /
Í
52
15 KGT-M9193-00 NUT PLATE 4 /
53
16 KGY-M9140-A0 PULLEY,CONV. ASSY 4 /
54
17 KH2-M9105-11
PULLEY,MOTOR:P30-3GT
2
/
55
18
KH2-M9121-00 BEARING
2
/
Í
56
19 KKE-M9119-A0
PULLEY CONV. ASSY. 4
/
57
20 KKE-M9120-A0 PULLEY CONV. ASSY 2
/
58
21 KKE-M9128-00 BELT 222-3GT-9 1 /
Í
59
22 KKE-M917J-00 PULLEY 1,MOTOR 1 /
Í
60
23 KKH-M9136-00 PLATE,EDGE 3 8 /
61
24 KLT-M9113-00 GUIDE,END 1 2 /
62
25 KLT-M9114-00 GUIDE,END 2 2 /
63
26 KLT-M9115-00 BRKT.1,SPLINE 1 /
Í
64
27 KLT-M9117-00 SPLINE 1 1 /
Í
65
28 KLT-M9118-00 BRACKET,COLLAR 1 /
Í
66
29
KLT-M9127-00 BELT,CONVEYOR 1 2
E
67
30 KLT-M9137-00 BRKT.,CONV.MOTOR 1 /
Í
68
31 KLT-M9157-00 SHAFT,MOTOR 1 /
Í
69
32 91312-06010 BOLT HEX,SOCKET HEAD 2
70
33 92902-05200 WASHER,PLAIN 8
71
34 92902-05600 WASHER,PLAIN 4
72
35 92A08-04303 SCREW SET 4
73
36 98702-03005 SCREW,FLAT HEAD 3
74
37
75
38
76
5
3
Transport
Conveyor
