KLT-1406
Rev. :It had a change without the compatibility. Please be careful at the time of the parts ordering.
Rev.: 過去に互換性の無い変更が入った部品。部品発注時は注意してください。
No. Part No. Part Name Q’ty Remarks Rev. Rank Level No. Part No. Part Name Q’ty Remarks Rev. Rank Level
1 91312-03005 BOLT HEX,SOCKET HEAD 4
39
2 91312-03006 BOLT HEX,SOCKET HEAD 30
40
3 91312-03008 BOLT HEX,SOCKET HEAD 30
41
4 91312-04008 BOLT HEX,SOCKET HEAD 6
42
5 91312-04010
BOLT HEX,SOCKET HEAD 4
43
6 92902-04200 WASHER,PLAIN
4
44
7
92A08-03304
SCREW SET 2
45
8
95302-03700 NUT HEXAGON
32
46
9 KHM-M654C-01 SENSOR, FIBER 2 2 FIBER B
Í
47
10 KHW-M9157-00 HOLDER,SENSOR 1 /
Í
48
11 KLT-M653A-00 SEN. INSPECT ASSY. 1
FIBER & AMP (Main ST)
B
Í
49
12 KLT-M653A-A0 SEN. INSP. AMP ASSY. 1 AMP B
Í
50
13 KLT-M653D-00 SEN. RIGHT ASSY. 1
FIBER & AMP (RIGHT)
B
Í
51
14 KLT-M653D-A0 SEN. R AMP ASSY. 1 AMP B
Í
52
15 KLT-M653E-00 SEN. LEFT ASSY. 1
FIBER & AMP (LEFT)
B
Í
53
16 KLT-M653E-A0 SEN. L AMP ASSY. 1 AMP B
Í
54
17 KLT-M653R-00
SENSOR, FIBER 1 1
FIBER B
Í
55
18 KLT-M9122-00
GUIDE 4
/
Í
56
19
KLT-M9123-00 BRKT.,SENSOR 1
1
/
Í
57
20 KLT-M9124-00 BRKT.,SENSOR 2 1
/
Í
58
21 KLT-M9134-00 GUIDE,HNS. 3 1
/
Í
59
22 KLT-M9135-00 GUIDE,HNS. 4 1 /
Í
60
23 KLT-M9136-00 PLATE,HNS. 3 1 /
Í
61
24
KLT-M9151-00 PLATE,GUIDE 1 4
/
Í
62
25 KLT-M9152-00 PLATE,GUIDE 2 2 /
Í
63
26 KLT-M9153-00 PLATE,GUIDE 3 2 /
Í
64
27 98502-03004 SCREW PAN HEAD 2
65
28
66
29
67
30
68
31
69
32
70
33
71
34
72
35
73
36
74
37
75
38
76
5
4
Sensor / Plate (STD)
Conveyor
KLT-1406
25
7 (11)
7 (11)
24
26
25
24
7 (9)
26
21
25
4
30
17 (15)
4
29
23
18
8
8
7 (9)
27
3
28
3
2
1
4
2
17 (15)
22
19
3
6
5
7 (13)
2
29
18
18
27
2
3
2
28
2
3
7 (11)
2
31
18
31
1
2
7 (13)
26
26
20
16 (15)
14 (13)
6
2
12 (11)
5
3
10 (9)
28
27
2
25
7 (9)
28
27
5
5
Sensor / Plate (Second Main)
Conveyor
KLT-1406
Rev. :It had a change without the compatibility. Please be careful at the time of the parts ordering.
Rev.: 過去に互換性の無い変更が入った部品。部品発注時は注意してください。
No. Part No. Part Name Q’ty Remarks Rev. Rank Level No. Part No. Part Name Q’ty Remarks Rev. Rank Level
1 91312-03005 BOLT HEX,SOCKET HEAD 4
39
2 91312-03006 BOLT HEX,SOCKET HEAD 34
40
3 91312-03008 BOLT HEX,SOCKET HEAD 32
41
4 91312-04008 BOLT HEX,SOCKET HEAD 6
42
5 91312-04010
BOLT HEX,SOCKET HEAD 4
43
6 92902-04200 WASHER,PLAIN
4
44
7
KHM-M654C-01
SENSOR, FIBER 2 3
FIBER B
Í
45
8
KHW-M9157-00 HOLDER,SENSOR
2
/
Í
46
9 KLT-M653A-00 SEN. INSPECT ASSY. 1
FIBER & AMP (Main ST)
B
Í
47
10 KLT-M653A-A0 SEN. INSP. AMP ASSY. 1 AMP B
Í
48
11 KLT-M653C-00 SEN. WORK ASSY. 1
FIBER & AMP (Second Main ST)
B
Í
49
12 KLT-M653C-A0 SEN. WORK AMP ASSY. 1 AMP B
Í
50
13 KLT-M653D-00 SEN. RIGHT ASSY. 1
FIBER & AMP (RIGHT)
B
Í
51
14 KLT-M653D-A0 SEN. R AMP ASSY. 1 AMP B
Í
52
15 KLT-M653E-00 SEN. LEFT ASSY. 1
FIBER & AMP (LEFT)
B
Í
53
16 KLT-M653E-A0 SEN. L AMP ASSY. 1 AMP B
Í
54
17 KLT-M653R-00
SENSOR, FIBER 1 1
FIBER B
Í
55
18 KLT-M9122-00
GUIDE 4
/
Í
56
19
KLT-M9123-00 BRKT.,SENSOR 1
1
/
Í
57
20 KLT-M9124-00 BRKT.,SENSOR 2 1
/
Í
58
21 KLT-M9134-00 GUIDE,HNS. 3 1
/
Í
59
22 KLT-M9135-00 GUIDE,HNS. 4 1 /
Í
60
23 KLT-M9136-00 PLATE,HNS. 3 1 /
Í
61
24
KLT-M9151-00 PLATE,GUIDE 1 2
/
Í
62
25 KLT-M9152-00 PLATE,GUIDE 2 2 /
Í
63
26 KLT-M9153-00 PLATE,GUIDE 3 2 /
Í
64
27 KLT-M9154-00 PLATE,GUIDE 4 2 /
Í
65
28 KLT-M9155-00 PLATE,GUIDE 5 2 /
Í
66
29 92A08-03304 SCREW SET 2
67
30 95302-03700 NUT HEXAGON 38
68
31 98502-03004 SCREW PAN HEAD 4
69
32
70
33
71
34
72
35
73
36
74
37
75
38
76
5
5
Sensor / Plate (Second Main)
Conveyor
