Contents
1
Base Section
Base .....................................................................1-1
2
Cover Section
Top Cover 1 ..........................................................2-1
Top Cover 2
..........................................................2-2
Acryl Door
.............................................................2-3
Base
.....................................................................2-4
3
Moving-axis Section
X-axis ....................................................................3-1
Y-axis
....................................................................3-2
4
Head Section
Head Camera (12M). ............................................4-1
Head Camera (5M).
..............................................4-2
5
Conveyor Section
(Single Lane)
Push Up ................................................................5-1
Stopper Assy
........................................................5-2
Transport
..............................................................5-3
Sensor / Plate (STD)
............................................5-4
Sensor / Plate (Second Main)...............................5-5
6
Conveyor Section
(Dual Lane)
Push Up ................................................................6-1
Stopper Assy 1
.....................................................6-2
Stopper Assy 2
.....................................................6-3
Transport
..............................................................6-4
Sensor / Plate (STD)
............................................6-5
Sensor / Plate (Second Main)...............................6-6
7
Marker Section (OP)
Marker Pen Unit ....................................................7-1
8
Controller Section
Controller .............................................................8-1
9
Exterior, etc. Section
Exterior, etc. ..........................................................9-1
10
Tools Section
Tools ...................................................................10-1
KLT-1506
8
17
25
26
13
24
14
14
28
3
1
27
5
23
15
22
16
12
10
29
12
11
20
14
7
6
4
18
12
24
21
2
19
12
9
25
12
1
1
Base
Base
KLT-1506
Rev. :It had a change without the compatibility. Please be careful at the time of the parts ordering.
Rev.: 過去に互換性の無い変更が入った部品。部品発注時は注意してください。
No. Part No. Part Name Q’ty Remarks Rev. Rank Level No. Part No. Part Name Q’ty Remarks Rev. Rank Level
1 $KM-10 MUFFLER 1 39
2 $SL4-01 JOINT 1 40
3 $SL8-01 JOINT 1 41
4 $UC4 JOINT 1 42
5 $UL10 JOINT 1 43
6 $UY4 JOINT 1 44
7 $UY8 JOINT 2 45
8 90563-03J450 SPACER 4 46
9 91312-03006 BOLT HEX,SOCKET HEAD 4 47
10 91312-03030 BOLT HEX,SOCKET HEAD 4 48
11 91312-04006 BOLT HEX,SOCKET HEAD 2 49
12 91312-05008 BOLT HEX,SOCKET HEAD 10 50
13 91312-05010 BOLT HEX,SOCKET HEAD 2 51
14 KGA-M1180-00 LEVELING BOLT ASSY. 4 /
52
15 KLT-M8582-00 VALVE 1
3valves
B
Í
53
16 KHW-M8582-40 VALVE 1 B
54
17 KHY-M11B0-00 AIR TAG 1 /
55
18 KJJ-M4554-00 TERMINAL BOARD ASSY 1 B
Í
56
19 KKE-M111G-00 COVER,TERMINAL 1 /
57
20 KKT-M1129-00 PLATE,TERMINAL 1 /
Í
58
21 KLC-M8505-00 REGULATOR COMB.
1 B
Í
59
22 KLC-M8506-00 FILTER ELEMENT 1 E
60
23 KLC-M8507-00 MIST FILTER ELEMENT 1 E
61
24 KLF-M115J-00 FILTER ,CP FAN 2 E
62
25 KLT-M0114-00 AIR TML. SUB ASSY.,3 2 /
Í
63
26 KLT-M1111-00 PLATE 11 1 /
Í
64
27 KLT-M1123-00 PLATE 23 1 /
Í
65
28 KLT-M1125-00 PLATE 25 1 /
Í
66
29 KLT-M8501-01 AIR COMB. 1 /
67
30 68
31 69
32 70
33 71
34 72
35 73
36 74
37 75
38 76
