SUSS / PA300 / User Manual / M10-121841-00 / February 2002
47
Weight
Device without table 500 kg
Device with table 600 kg
Electronics 13 kg
Temperature
Optimal operating range 19°C ... 24°C
Target temperature 22°C
Tolerance 1K
Max. rate of change/hour Not specified
Electronics ProberBench Side ventilators and air expellers must be
kept clear for air circulation at all times.
Humidity
Tool area 40 % ... 60 %
Support equipment area 40 % ... 60 %
Noise
Audio Noise Constant level: 56 dB (A) Impulse: 72 dB (A)
Pollution Level 1 IEC 664
Clean Room Class Class 6 corresponding to
DIN EN ISO 14664-1
Electrical Data
Power 230 V, 50 Hz, 510 VA or 120 V, 60 Hz,
510 VA (according to type)
Protection Class I
Transient overvoltage Overvoltage category II
Fuses
Main Power – external 2 x 2 A sluggish (230 V) or 2 x 4 A sluggish
(120 V) 1/4” x 1 1/4” Spiral type
EMO Main Power Supply (internal) 1x 500 mA sluggish (F1)
1x 125 mA sluggish (F2)
Size 5 mm x 20 mm
Power Supply Probe System 28 V d.c. 5 V d.c.
Power Supply EMO System 24 V a.c.
48
SUSS / PA300 / User Manual / M10-121841-00 / February 2002
Utility Distribution
Concentric Socket INK 1 .. 4 Optional use (DC impulse up to 28 V d.c.)
Concentric Socket Edge 1, 2 Optional use (edge switch)
Airbourne socket J7 Optional use
Pin configuration In the plug
0 V (GND) Contacts 1 and 2, bridged
+ 5 V d.c. Contacts 6 and 7, bridged
+ 28 V d.c. Contacts 3 and 4 and 5, bridged
Affiliated fuses:
+ 5 V d.c. 1 A sluggish (F5)
+ 28 V d.c. 1 A sluggish (F6)
5 mm x 20 mm
SUSS / PA300 / User Manual / M10-121841-00 / February 2002
49
10.3 Ergonomic Information Table
Indicator Part
SESC
Criteria
Actual value Notes
Manual Material
Handling
2 hand lifting or
lowering tasks: if object
weighs more than
22.5N
If larger, analysis
is necessary
Smaller than
22.5N
N/A
Product Loading in a
Standing Position
Clearance for finger
thickness
min. 38 mm >38 mm Yes
Clearance for hand
thickness
min. 76 mm
>76 mm
<240 mm
Yes
Reach distance from
leading edge of tool to
hand coupling point
max. 330 mm <330 mm Yes
Vertical coupling point
of hand to product in
load position
with KSD
vibration isolation
table
max. 1010 mm
min. 890 mm
norm 1077 mm
difference
67 mm
Wafer cassette
loading
N/A
Wafer cassette
storage
N/A
Manual cassette
rotation device
N/A
Handle design
(suitable for use with
cleanroom gloves)
vacuum tweezers optional use
Handle surface finish vacuum tweezers
Cylindrical handle
diameter
vacuum tweezers
max. 38 mm
min. 25 mm
(min. 19 mm -
SEMI S8-95A)
17 x 21 mm
2
difference
2 mm
Cylindrical handle
length
vacuum tweezers min. 127 mm 160 mm Yes
Other types of handle N/A
Maintainability and
Serviceability
Minimal lighting level min. 300 lux
to be supplied by
the customer
see
section
2.9
