48
SUSS / PA300 / User Manual / M10-121841-00 / February 2002
Utility Distribution
Concentric Socket INK 1 .. 4 Optional use (DC impulse up to 28 V d.c.)
Concentric Socket Edge 1, 2 Optional use (edge switch)
Airbourne socket J7 Optional use
Pin configuration In the plug
0 V (GND) Contacts 1 and 2, bridged
+ 5 V d.c. Contacts 6 and 7, bridged
+ 28 V d.c. Contacts 3 and 4 and 5, bridged
Affiliated fuses:
+ 5 V d.c. 1 A sluggish (F5)
+ 28 V d.c. 1 A sluggish (F6)
5 mm x 20 mm
SUSS / PA300 / User Manual / M10-121841-00 / February 2002
49
10.3 Ergonomic Information Table
Indicator Part
SESC
Criteria
Actual value Notes
Manual Material
Handling
2 hand lifting or
lowering tasks: if object
weighs more than
22.5N
If larger, analysis
is necessary
Smaller than
22.5N
N/A
Product Loading in a
Standing Position
Clearance for finger
thickness
min. 38 mm >38 mm Yes
Clearance for hand
thickness
min. 76 mm
>76 mm
<240 mm
Yes
Reach distance from
leading edge of tool to
hand coupling point
max. 330 mm <330 mm Yes
Vertical coupling point
of hand to product in
load position
with KSD
vibration isolation
table
max. 1010 mm
min. 890 mm
norm 1077 mm
difference
67 mm
Wafer cassette
loading
N/A
Wafer cassette
storage
N/A
Manual cassette
rotation device
N/A
Handle design
(suitable for use with
cleanroom gloves)
vacuum tweezers optional use
Handle surface finish vacuum tweezers
Cylindrical handle
diameter
vacuum tweezers
max. 38 mm
min. 25 mm
(min. 19 mm -
SEMI S8-95A)
17 x 21 mm
2
difference
2 mm
Cylindrical handle
length
vacuum tweezers min. 127 mm 160 mm Yes
Other types of handle N/A
Maintainability and
Serviceability
Minimal lighting level min. 300 lux
to be supplied by
the customer
see
section
2.9
50
SUSS / PA300 / User Manual / M10-121841-00 / February 2002
Indicator Part
SESC
Criteria
Actual Value Notes
Full body clearance
standing/ sitting
position
to be supplied by
the customer
see
section
2.9.1
Any posture: upper
body clearance
(shoulder width)
min. 610 mm
see
section
2.9.1
Standing position:
Height;
Width;
min. 1980 mm
min. 690 mm
to be supplied by
the customer
see
section
2.9.1
Sitting Position (on
floor):
Height;
Width;
Working height;
min. 1000 mm
min. 690 mm
min. 280 mm
to be supplied by
the customer
see
section
2.9.1
Squatting (on floor):
Height;
Width;
Working height;
min. 1220 mm
min. 790 mm
min. 460 mm
to be supplied by
the customer
see
section
2.9.1
Kneeling (on floor):
Height;
Width;
Working height;
min.1450 mm
min. 1220 mm
min. 640 mm
to be supplied by
the customer
see
section
2.9.1
Kneeling crawl (on
floor):
N/A
Stooping (on floor):
Height;
Width;
Working height;
min. 1450 mm
min. 1020 mm
min. 640 mm
to be supplied by
the customer
see
section
2.9.1
Supine (lying on back): N/A
Prone (lying on front): N/A
Hand/Arm Clearance
(for use with clean-
room gloves only)
Finger access
(diamater):
2, 3, or 4 finger access:
min. 32 mm
object + 58 mm
i.e.: PH150: 2
finger access,
>32 mm
Yes
Flat hand to wrist
access:
Height, palm thickness;
Width, palm width;
loading tray min. 89 mm
min. 114 mm
>89 x 114 mm
2
Yes
