SUSS / PA300 / User Manual / M10-121841-00 / February 2002 53 Indicator Part SESC Criteria Actual Value Notes Hand Control Location Standing work place Prober hand control location optional Location of infrequently used …
52
SUSS / PA300 / User Manual / M10-121841-00 / February 2002
Indicator Part
SESC
Criteria
Actual Value Notes
Height of monitors used less
than once an hour (from floor
to top of screen)
max. 1680 mm N/A
Height of monitors used less
than once an day (from floor
to top of screen)
max. 2130 mm N/A
Height of touch screen
monitor
max. 1370 mm
min. 910 mm
N/A
Tilt of touch screen between
41" and 48"
min. 30° upwards N/A
Tilt angle of touch screen <
41"
min. 45° upwards N/A
Location of Operator
Primary Interface (sitting)
computer:
sitting
position
when using a PC
Height of monitor (from floor
to middle of screen)
max. 1190 mm
min. 940 mm
according to
configuration, 1
or 2 monitors,
location to be
determined by
customer
see
section
2.9.2
Height of monitor (from floor
to top of screen)
max. 1400 mm
min. 940 mm
according to
configuration, 1
or 2 monitors,
location to be
determined by
customer
see
section
2.9.2
Tilt angle of screen >55"
min. 15°
downwards
N/A
Height of touch screen (from
floor to active block)
max. 1070 mm
min. 760 mm
N/A
Display Characteristics
Lateral distance from display
to input device
max. 320 mm
location to be
determined by
customer
see
section
2.9.2
Character height (specific to
Chinese, Korean and
Japanese characters)
character height
>= visual
distance (457
mm - 762 mm)
divided by 143
N/A
Character height (except for
Chinese, Korean and
Japanese characters)
character height
>= visual
distance (457
mm - 762 mm)
divided by 215
devices to be
provided by
customer
see
section
2.9.2
SUSS / PA300 / User Manual / M10-121841-00 / February 2002
53
Indicator Part
SESC
Criteria
Actual Value Notes
Hand Control
Location
Standing work place Prober
hand control
location optional
Location of infrequently
used controls (less than
once evrey 24 hours)
measured from floor to
center of control
Height:
max. 1640 mm
min. 280 mm
min. 260 mm
max. 1080 mm
N/A
Location of infrequently
used controls: should
not be located below
838 mm or above 1683
mm; interpolate for
immediate values:
1638 mm
1525 mm
1422 mm
1321 mm
1219 mm
1118 mm
1016 mm
914 mm
838 mm
min.
ProberBench
max. electronic
connection box
lid
254 mm
368 mm
432 mm
470 mm
483 mm
470 mm
393 mm
292 mm
178 mm
min. 260 mm
max. 1080 mm
table to be
supplied
by
customer
Location of frequently
used controls: should
not be located below
940 mm or above 1270
mm; interpolate for
immediate values:
1270 mm
1219 mm
1168 mm
1118 mm
1067 mm
1016 mm
940 mm
joystick and
keyboard
distance from
operator to
controls:
292 mm
330 mm
368 mm
394 mm
406 mm
394 mm
318 mm
table to be
supplied by
customer
see
section
7.2.2
54
SUSS / PA300 / User Manual / M10-121841-00 / February 2002
Indicator Part
SESC
Criteria
Actual Value Notes
Sitting work place
computer: sitting
work place
table to be
supplied by
customer
Location of frequently
used controls: should
not be located below
533 mm or above 1378
mm; interpolate for
immediate values:
1397 mm
1270 mm
1169 mm
1067 mm
965 mm
864 mm
762 mm
660 mm
533 mm
distance from
operator to
controls:
356 mm
432 mm
470 mm
483 mm
483 mm
470 mm
445 mm
381 mm
254 mm
N/A
Location of infrequently
used controls: should
not be located below
762 mm or above 1067
mm; interpolkate for
immediate values:
1067 mm
1016 mm
995 mm
914 mm
864 mm
813 mm
762 mm
distance from
operator to
controls:
330 mm
368 mm
394 mm
406 mm
419 mm
419 mm
419 mm
table to be
supplied by
customer
see
section
7.2.2
Workstation Design
Standing work place Prober
Work surface edge
radius where the
operator can assume a
static posture in contact
with the edge
radius min. 6.4
mm
work surface
should not be
leant against
see
section
2.9.1
Height of keyboard,
trackball or mouse
max. 1020 mm
min. 970 mm
location to be
determined by
customer
see
section
2.9.1
