SW 703 Option WPC - Option WPC :

101

SW 703 Option WPC

SW 703 Option WPC - Condition Of The Carrier :

102

Condition Of The Carrier

1. Condition of the carriers should be accessed prior to

loading into the WPC. Trays with bent or dented

edges are deem unfit for use

2. Do not attempt to rectify the defect by any means

Note: Dispose defective carrier, if found.

SW 703 Option WPC - Numbering System Of Level :

103

Numbering System Of Level

The carrier has a total of 28 trays.

1. A numbering chart with bar code is found at top left

corner inside the unit

2. Numbering of the tray starts from the bottom:

Lowest level = 1

Highest level = 28
