00196851-02 OG SIPLACE Operation of X and SX-Series with SSC (SW70x) - 第164页
703-Handling Messages - Messages – Statistics – Location 1 : 164
703-Handling Messages - Messages – Statistics – Location 1 :
163
Messages – Statistics – Location 1
1. List of current messages related to location 1
2. Display of errors by segment number.
3. Display of errors by feeder track number.
4. Graphical display of errors.
5. Vision errors.
6. Pick up errors.
7. Component sensor errors.
8. Switch to display location 2 errors.
703-Handling Messages - Messages – Statistics – Location 1 :
164
Weekly PM (70x) - Preparations for Maintenance – Materials :
165
Weekly PM (70x)
Have everything ready before you start maintenance!
The following materials are needed:
1. Vacuum Cleaner.
2. SIPLACE Cleaning Tissues (Part No. 00315253-02).
3. Dry Lint free cloths.
4. Ethanol Alcohol.
5. Nozzle cleaning appliance (Part No 03055736-01 for
CP20 head & 03076627-01 for CPP head)
6. Ultrasonic bath (Part No 03042652-01)
7. Distilled Water.
8. Nozzle Grove Plate (Part No 03066508-01)
9. Nozzle Cleaning Brush ( Part No 00325866-01)
10. Small Dry brush
