Machine Safety (70x) - Warning Labels - Permanent Magnets :
16
Warning La bels - Permanent Magnets
SIPLACE HS-, HF-, D and X-series machines have linear
drives which use very powerful Permanent Magnets. Be
careful while working close to these magnets.
1. Strong Permanent Magnets present
2. Danger of crushing for people with passive metal
implants (plates, screws, etc.)?
3. Potential damage to keys, credit cards, watches, etc.
4. Great danger for people with active implants
(pacemakers, insulin pumps, defibrillators)
Machine Safety (70x) - Warning Labels - Tape Cutters :
17
Warning Labels - Tape Cutters
All SIPLACE machines are equipped with tape cutters
that have very sharp blades. Be careful while working
near the tape cutters.
1. Risk of cutting – danger of cutting is possible even
when the machine is turned off
2. Used tape chute – never reach up above the tape
chute
3. Used tape channel - never reach into the opening of
the channel
Machine Safety (70x) - Warning Labels - Lasers :
18
Warning Labels - Lasers
1. Laser Class 1 – for the stationary cameras (used by
the P&P and Twin Heads) and PCB camera
2. Laser Class 1M – for the C&P head cameras
3. Laser Class 2 - Do not look into the beam – for the
conveyor system light barriers, PCB barcode readers
and Coplanarity module option
