Machine Overview (70x) - Basic m ac hines in a typical SMT line setup : 29 Machine Ov erview (7 0x) 1. Bare boa rd input 2. Board loader 3. Printer 4. Side of Inspection 5. Placement machines 6. Side of Inspection 7. Ref…
Machine Safety (70x) - Further Safety Information :
28
Machine Overview (70x) - Basic machines in a typical SMT line setup :
29
Machine Overview (70x)
1. Bare board input
2. Board loader
3. Printer
4. Side of Inspection
5. Placement machines
6. Side of Inspection
7. Reflow oven
8. Board unloader
9. Complete board output
Machine Overview (70x) - SIPLACE X-Series machine types :
30
SIPLACE X-Series machin e types
Machine types
1. SIPLACE X4 / X4i
2. SIPLACE X3
3. SIPLACE X2
Station control
4. GUI Software – 703.
