Machine Overview (70x) - SIPLACE X-Series machine types :
30
SIPLACE X-Series machin e types
Machine types
1. SIPLACE X4 / X4i
2. SIPLACE X3
3. SIPLACE X2
Station control
4. GUI Software – 703.
Machine Overview (70x) - SIPLACE X-Series machine setup :
31
SIPLACE X-Series machine setup
General Overview
1. Placement heads
2. Changeover table
3. Changeover table / MTC
4. Buffer zone
5. Nozzle changer row 1 (row 2 optional)
(T) Transport Direction.
Machine Overview (70x) - SIPLACE X-Series machine setup :
32
SIPLACE X-Series machine setup
General Overview
1. Placement head 1
2. Placement head 2
3. Placement head 3
4. Placement head 4
5. Operator panel
6. Placement area 1
7. Placement area 2
(T) Transport Direction.
(R) Right side of machine.
(L) Left side of machine.
(F) Front of machine.
(B) Back of machine.
