Machine Overview (70x) - SIPLACE SX-Series machine setup :
34
SIPLACE SX-Series mac hine setup
General Overview
1. Gantry 1
2. Ganrty 2
3. Changeover tables
4. Operator panels
(T) Transport Direction
(R) Right of machine
(L) Left of machine
Machine Overview (70x) - SIPLACE SX-Series machine setup :
35
SIPLACE SX-Series mac hine setup
General Overview
1. Stationary camera
2. Nozzle changers
3. Optional 2nd row of nozzle changers.
(T) Transport Direction
(R) Right of machine
(L) Left of machine
Machine Overview (70x) - SIPLACE placement heads and conveyor types :
36
SIPLACE placement he ads and conveyor types
Placement heads
1. CPP Head (MultiStar)
2. C&P20 head (SpeedStar)
3. Twin head (TwinStar)
PCB conveyor
4. Single lane
5. Dual lane
