Machine Overview (70x) - S IPLACE feede r modules : 38
Machine Overview (70x) - SIPLACE feeder modules :
37
SIPLACE feeder modu les
X-Tape feeder modules
1. Change over table X
2. X-Feeder 8mm – 88mm
Tray feeder modules
3. MTC (X only)
4. WPC (SX only)
Alternative feeder modules
5. Linear Vibratory feeder.
Machine Overview (70x) - SIPLACE feeder modules :
38
