SW 703 Option MTC - Option - MTC :
85
SW 703 Option MTC
The next pages contain details of how to prepare the set
up of the Option Matrix Tray Changer (MTC)
SW 703 Option MTC - Numbering System Of Levels (Towers 1 & 2) :
86
Numbering Syst em Of Levels (T owers 1 & 2)
Tower 1 has a total of 5 cassettes XL and 30 carriers.
Tower 2 has a total of 4 cassettes and 40 carriers.
1. A numbering chart with bar code is found at top left
corner inside the unit
SW 703 Option MTC - Numbering System Of Levels (Towers 1 & 2) :
87
Numbering Syst em Of Levels (T owers 1 & 2)
1. Numbering of the metal carrier starts from the bottom:
Tower 1
Lowest level = 1
Highest level = 30
Tower 2
Lowest level = 1
Highest level = 40
2. Numbering of the Cassette XL starts from the bottom
Tower 1
Lowest level = 1
Highest level = 6
Tower 2
Lowest level = 1
Highest level = 4
