SW 703 Option MTC - Loading Position Of The Carrier (Tower 1) :
90
Loading P osition Of The Carrier ( Tower 1)
1. Check if all carriers are loaded into the MTC tower 1
in correct orientation with the hinge facing outward
WARNING! A crash may occur if the above step
is not followed.
SW 703 Option MTC - Loading Position Of The Carrier (Tower 2) :
91
Loading P osition Of The Carrier ( Tower 2)
1. Check if all carriers are loaded into the MTC tower 2
in correct orientation with the tray adaptor facing
outward
WARNING! A crash may occur if the above step
is not followed.
SW 703 Option MTC - Magnets Under The Carrier :
92
Magnets Under The C arrier
1. Physically check if there are magnets from the bottom
carrier stuck underneath the carrier above.
WARNING! Magnets under the tray could result
in a crash! Take care to avoid this!
