00196851-02 OG SIPLACE Operation of X and SX-Series with SSC (SW70x) - 第98页
SW 703 Option MTC - Refill Completed : 98 Refill Comple ted 1. Click on the bottom left icon to return to the main menu. 2. The machine is now rea dy to start production.
SW 703 Option MTC - Moving to the Refill position :
97
Moving t o the Refil l position
1. Click on ‘Refill position’
2. Click on ‘Move to refilling position’
SW 703 Option MTC - Refill Completed :
98
Refill Comple ted
1. Click on the bottom left icon to return to the main
menu.
2. The machine is now ready to start production.
SW 703 Option MTC - MTC verification :
99
MTC verifica tion
The MTC setup verification can be carried out separately
for each location.
1. Check and see if the setup is displayed as online
setup in Setup Center.
2. Scan the control barcode Table verification of the
location to be verified. Check if you at the right track.
3. Scan all configured barcodes of the packaging unit.
Repeat step 4 until all the necessary tracks for the
current job are verified.
NOTICE! Depending on the configuration of
Setup Center further steps can be necessary during
online setup verification. Therefore always watch the
display of the barcode reader.
e.g. scanning of user or reordering a packaging unit.
