semi automatic (55250( 66$* (6 ,1752'8& 7,21 Software Version 07SP02 User Manual 3.1 CHAPTER 3 ERROR MESSAGES INTRODUCTION If for any reason the machine does not compl ete a particular seque nce in the time all…
semi automatic
6(735()(5(1&(6
35()(5(1&(6
2.6 User Manual Software Version 07SP02
2. Type vorton using the keyboard.
3. Press Enter, the message ‘Vortex Under-Screen Cleaner Enabled ’is
displayed in the message prompt bar.
The Vortex under screen cleaner becomes the current cleaner and all
cleaner parameters become appropriate to the Vortex cleaner.
The value of the configuration parameter cleaner type is set to Vortex and
this parameter is written to the configuration file.
4. Press Exit.
To disable the Vortex under screen cleaner carry out the following:
1. Press the function key F10 on the keyboard, a window of the following form
is displayed:
2. Type vortoff using the keyboard.
3. Press Enter, the message Vortex Under-Screen Cleaner Disabled is
displayed in the message prompt bar.
4. Press Exit.
Board Stop X
Offset
This parameter allows a value to input which compensate for variations in the
focal lengths of the vision systems between machines.
Machine Location This allows the operator to enter text to uniquely identify the machine. Output
is via SPC.
On selecting Incr. with machine locations highlighted, the message ‘Please
type in the text, then press Return’ is displayed. The menu softkeys are
blanked out.
Generic Tooling This preference enables enhanced tooling setup, allowing the operator to step
between various elevations of the rising table between home height and contact
height. At contact height an operator can check that the setup of the tooling is
adequate for the current product. The options are:
Enter to Close ...
Serial Number
Executable date
Executable time
Executable name
Software Version
Options Enabled
:
:
:
:
:
:
276178
August 19 2002
10:57:38
RTX494.EXE
RTX494.00
BF
DEK VIKING
Minimum Maximum Default
20mm 40mm 28mm
Options Default
Enabled Enabled
Disabled
semi automatic
(55250(66$*(6
,1752'8&7,21
Software Version 07SP02 User Manual 3.1
CHAPTER 3 ERROR MESSAGES
INTRODUCTION
If for any reason the machine does not complete a particular sequence in the
time allowed for in software, an error condition arises. The relevant error
message is displayed on the machine monitor.
Machine Errors are detected by sensors specifically designed for checking
correct machine status (System Power, Pneumatic Power, etc.) or by functions
failing to achieve their correct operation. These latter errors are either detected
by a limit sensor being operated or by setting a time limit for their completion.
The time limits are set so they are 1.5 times the longest possible time taken for
that particular operation, after which, if not completed, an error is reported on
the machine monitor.
When an error occurs the relevant message is displayed on the machine
monitor. The displayed error message is accompanied by information regarding
the possible causes and the corrective action to be taken.
semi automatic
(55250(66$*(6
(55255(&29(5<
3.2 User Manual Software Version 07SP02
ERROR RECOVERY
When an error message is displayed the following options maybe available to
recover the machine:
Abort Pressing this option re-initializes the entire printer, ejecting any product that may
be in the printer and returning to the main control page.
Retry Selecting this option re-checks the error condition and if clear continues the print
cycle.
Recover Pressing this option attempts to continue with any cycle that is in operation. This
function sets modules (paste dispenser, print carriage, etc.) to their home
position and ejects the board that is currently in the printer without re-initializing
the machine. This option should be the first to be operated if there is an error
reported.
Diagnostics This option enables the diagnostics to be entered immediately, normally by a
technician, for more in-depth investigation of the problem.
Open Cover This option allows the operator to select ‘Change Screen’ to gain access to the
tooling area of the machine.
Continue When this option is available, selecting the continue key clears the error
message and continue with the cycle that is in operation.
Fiducial Setup When this option is available, selecting the Fiducial Setup key allows the user
to relearn the reported ‘Not Found’ fiducial.
Search Step When this option is available, selecting the Search Step key moves the camera
the first step in a search procedure designed to locate the ‘Not Found’ fiducial.
Further selection of the key moves the camera to the second step etc. Once
the fiducial is visible in the region of interest, the Retry key can be selected to
capture the fiducial.
Search Reset When this option is available, selecting the Search Reset key returns the
camera to its original position, before the Search Step key was selected. This
is the position from which the ‘Not Found’ fiducial was reported.
