Screen Cleaner Out Of Position This error reports that the screen cleaner is out of position. Possible causes
are:
Screen Cleaner not at the home position.
Home sensor - enter Diagnostics, Digital Inputs and check the sensor changes
state.
If a screen cleaner is not fitted, check that the home sensor is not connected.
Screen Couplings Not Extended This error reports that the screen couplings have failed to extend within the 4
second time-out period.
Screen XF Error This error reports that the X forward screen actuator failed to initialize to its
central datum.
Screen XR Error This error reports that the X rear screen actuator failed to initialize to its central
datum.
Screen Y Error This error reports that the Y screen actuator failed to initialize to its central
datum.
Set Pressure %2.21f Actual Pressure
%2.21f (Front/Rear Squeegee)
This error reports if the front/rear squeegee pressure differs from the pressure
set by more than ± 1.00Kg.
System Power Down This error reports that the 24V motor power has been switched off either by the
Emergency Stop button being activated or that the removable frame access
cover has been removed.
System Suspended While Covers Open This error reports that whilst the machine was switched on, one or more of the
cover interlock switches were out of position.
Table Movement Inhibited,
Camera Not Home.
This error reports that the camera is over the table and the NextMove is sent
an instruction to move the rising table.
This Diagnostic Cannot Run
Until Proflow Is At home
This error reports if proflow is not in the home position (Print Carriage Diagnos-
tics only).
This Diagnostic Cannot Run With
Proflow Fitted
This error reports if in Print Carriage Diagnostics, Move Print Carriage to Paste
Position is selected.
Unable to Find Fiducial This error reports that the vision system is unable to locate the relevant screen
or board fiducial.
Window Error This error reports that the menu structure has failed to open correctly.
X Actuator Limit Exceeded This error reports that either X actuators are driven past its limit set during
calibration.
Y Actuator Limit Exceeded This error reports that the Y actuator is driven past its limit set during calibration.
Error Message Interpretation
semi automatic
',$*1267,&6
,1752'8&7,21
Software Version 07SP02 User Manual 4.1
CHAPTER 4 DIAGNOSTICS
INTRODUCTION
The diagnostic function is an aid to the user to allow individual access and
control of motors and modules. It allows the user to control the sequence of the
machine so that a particular module can be exercised.
To enter the diagnostic mode press the Maint button.
The menu bar changes displaying the Diagnostic option.
Press the Diagnost (F6) button. If a password exists a window displays the
message ‘Diagnostic Password’. If the password is incorrect control displays
the message‘Invalid password entered’ and returns to the previous menu. If
the correct password is entered or no password exists a pop up window displays
the following:
The menu bar changes displaying the following:
Next / Previous keys move the highlight bar up and down the list of diagnostic
modules.
Select Module key opens a new window displaying the diagnostic functions
available for the selected module.
Exit returns operation to the start of initialization.
NOTE
Before any diagnostic function is used in any of the modules they must be
homed first or they are not able to initiate a command.
Run
Open
Cover
Paste
Load
Clean
Screen
Setup Monitor Maint.
Calibrat
Pressure
Calibrat
Offset
Calibrat
Vision
House
Keeping
Set
Prefs
Diagnost
Te st
Cycles
Exit
Module Diagnostic Page
System
Print Carriage
ProFlow / Squeegee
Camera Axes
Rail System
Paste Dispense System
Screen Alignment
Screen Change
Screen Cleaner
Rising Table
Select
Module
Next Previous Exit
semi automatic
',$*1267,&6
6<67(0
4.2 User Manual Software Version 07SP02
SYSTEM
Selecting this diagnostic module opens the following window:
The menu bar changes displaying the following:
Next / Previous keys move the highlight bar up and down the list of selectable
diagnostic functions.
Run Diagnost activates the diagnostic function, as selected by the highlight
bar.
Exit returns operation to the module diagnostic page.
Display All Digital
Inputs
Selecting this diagnostic function opens the following window:
The menu bar changes displaying the following:
Next / Previous keys move the highlight bar up and down the list of diagnostic
modules.
Select key opens a new window displaying the diagnostic functions available
for the selected option.
Exit returns operation to the system diagnostics page.
System Diagnostics
OFF
Display all Digital Inputs
Display all Analogue Inputs
Toggle Lid Bolt
Change Edit Password
Change Diagnostics Password
Change Terminate Password
Change Fiducial Set-Up Password
Change Maintenance Password
Terminate Control Program
Run
Diagnost
Next Previous Exit
Digital Group
NM 1 Group 0
NM 1 Group 1
NM 1 Group 2
NM 1 Group 3
NM 1 Group 4
MMOV 1 Group 0
MMOV 1 Group 1
MMOV 1 Group 2
MMOV 1 Group 3
MMOV 2 Group 0
MMOV 2 Group 1
MMOV 2 Group 2
MMOV 2 Group 3
Select Next Previous Exit
