semi automatic ',$*126 7,&6 35,17&$55 ,$*( 4.8 User Manual Software Version 0 7SP02 PRINT CARRIAGE Selectin g this diagnos tics modul e opens the fol lowing wi ndow: The menu bar changes to the following : …
semi automatic
',$*1267,&6
6<67(0
Software Version 07SP02 User Manual 4.7
Change Terminate
Password
Selecting this diagnostic function either allows a password to be entered or
changes an existing password. This password protection inhibits unauthorized
operation of the terminate control program.
Change Fiducial
Set-up Password
Selecting this diagnostic function allows a password to be entered or changes
an existing password. This password protection inhibits unauthorized entry into
the fiducial setup.
Change
Maintenance
Password
Selecting this diagnostic function allows a password to be entered or changes
an existing password. This password protection inhibits unauthorized entry into
the maintenance functions.
Terminate Control
Program
Selecting this diagnostic function terminates the control program and returns to
Windows NT.
semi automatic
',$*1267,&6
35,17&$55,$*(
4.8 User Manual Software Version 07SP02
PRINT CARRIAGE
Selecting this diagnostics module opens the following window:
The menu bar changes to the following:
Next / Previous keys move the highlight bar up and down the list of selectable
diagnostic functions.
Run Diagnost activates the diagnostic function, as selected by the highlight
bar.
Exit returns operation to the module diagnostics page.
Adjust opens the following window:
The menu bar changes displaying the following:
Next / Previous keys move the highlight bar up and down the list of diagnostic
parameters.
Incr. / Decr. keys change the value of the selected diagnostic parameter.
Exit returns operation to the Print Carriage diagnostics page.
NOTE
These parameters are used in diagnostics only and have no affect on the
product board file.
Home Print
Carriage
Selecting this diagnostic function homes the print carriage, as set by its home
sensor. ‘Homing Print Carriage’ is displayed in the prompt box. It is always
advisable to home the print carriage before attempting to position it.
Print Carriage Diagnostics
Cycle Count
Done :-
0, To go :-
50
Home Print Carriage
Drive Carriage To Front Position
Drive Carriage To Paste Position
Drive Carriage To Rear Position
Drive Carriage Using Jog Buttons
Cycle Print Carriage
Run
Diagnost
Adjust Next Previous Exit
Print Carriage Diagnostic Parameters
FRONT PRINT SPEED
REAR PRINT SPEED
CYCLE COUNT
25
25
50.0
mm/s
mm/s
Cycles
Next Previous Incr. Decr. Exit
semi automatic
',$*1267,&6
35,17&$55,$*(
Software Version 07SP02 User Manual 4.9
Drive Carriage to
Front Position
Selecting this diagnostic function moves the print carriage to the front start
position of the print stroke. ‘Driving Carriage to Front Limit’ is displayed in
the prompt box.
Drive Carriage to
Paste Position
Selecting this diagnostic function moves the print carriage to a position that
clears the paste dispense unit if operated. ‘Driving Carriage to Paste Posi-
tion’ is displayed in the prompt box.
Drive Carriage to
Rear Position
Selecting this diagnostic function moves the print carriage to the end of the print
stroke. ‘Driving Carriage to Rear Limit’ is displayed in the prompt box.
Drive Carriage
Using Jog Buttons
Selecting this diagnostic function allows the user to position the print carriage
anywhere between the front and rear position using the two jog buttons. ‘Use
Left Jog Button to move Print Carriage towards front and the Right Jog
Button to move it towards the rear’ is displayed in the prompt box.
Cycle Print
Carriage
Selecting this diagnostic function starts a continuous cycle of driving the print
carriage between its front and rear limits, pausing at each end for 2 seconds.
‘Print Cycling’ is displayed in the prompt box. The cycle is terminated if the
Stop key is used or the set cycle count is reached.
Cycle Count This diagnostic function displays the amount of cycles done and the amount of
cycles to go to complete the cycle count.
