semi automatic ',$*12 67, &6 5$,/6<67 (0 Software Version 07SP02 User Manual 4.19 Cycle Count This diagnostic function displays the amount of cycles don e and the amount of cycles to go to complet e the cycl…
semi automatic
',$*1267,&6
5$,/6<67(0
4.18 User Manual Software Version 07SP02
Home Rail Width Selecting this diagnostic function drives the rail width motor to its home position
as determined by its home sensor.
Drive Rail to Board
Width
Selecting this diagnostic function drives the rail width motor to the width set by
the board width parameter.
Drive Rail Width
Using Two Button
Control
Selecting this diagnostic function drives the rail width motor using the jog
buttons. The right jog button drives the rail width motor forward at slow speed
and the left jog button drives it to the rear, stopping immediately the button is
released.
Drive Belts Using
Two Button
Control
Selecting this diagnostic function drives the belt motors using the jog buttons.
The right Jog button drives the belt motors to the right and the left Jog button
drives the belt motors to the left, stopping immediately the button is released.
Belt Speed
Calibration
Selecting this diagnostic function enables the belt speed calibration to be
carried out. For information on the belt speed calibration procedure see the
Technical Reference manual, Rail System chapter.
Toggle Board
Clamp
Selecting this diagnostic function alternately energizes and de-energizes the
board clamp, displaying On when energized and Off when de-energized.
Toggle Board Stop Selecting this diagnostic function alternately lowers and raises the board stop
housed in the camera assembly, displaying On when lowered and Off when
raised.
Cycle Board on
Belts
Selecting this diagnostic function starts a continuous cycle of driving the belts
to the right, until a board reaches the camera board stop, dwelling for 2 seconds
and driving the belts to the left, until a board reaches the board at left sensor,
dwelling for 2 seconds and repeating the cycle, until stop is pressed or the set
cycle count is reached.
Cycle Board Clamp Selecting this diagnostic function starts a continuous cycle of clamping and
unclamping the board clamps. ‘Cycling Clamps....’ is displayed in the message
prompt box.
Cycle Rails Selecting this diagnostic function drives the moveable rail from the home
position to the minimum board width and back to the home position. ‘Cycling
Rails....’ is displayed in the message prompt box.
Board Stop in
Position
This diagnostic function continuously displays the status of the board stop
lowered sensor.
Board at Stop This diagnostic function continuously displays the status of the board at stop
sensor.
Board at Left This diagnostic function continuously displays the status of the board at left
sensor. On is displayed if a board is detected on the rails at the left of the
machine.
semi automatic
',$*1267,&6
5$,/6<67(0
Software Version 07SP02 User Manual 4.19
Cycle Count This diagnostic function displays the amount of cycles done and the amount of
cycles to go to complete the cycle count.
semi automatic
',$*1267,&6
3$67(',63(16(6<67(0
4.20 User Manual Software Version 07SP02
PASTE DISPENSE SYSTEM
Selecting this diagnostics module opens the following window:
The menu bar changes to the following:
Next / Previous keys move the highlight bar up and down the list of selectable
diagnostic functions.
Run Diagnost activates the diagnostic function, as selected by the highlight
bar.
Exit returns operation to the module diagnostics page.
Carriage Home Selecting this diagnostic function drives the paste dispense carriage left to its
home position, as determined by its home sensor.
Drive Carriage to
Start Position
Selecting this diagnostic function drives the paste dispense carriage to the
position set by the paste start parameter.
Drive Carriage to
End Position
Selecting this diagnostic function drives the paste dispense carriage to the
position set by the paste stop parameter.
Drive Cartridge
Down
Selecting this diagnostic function drives the cartridge tilt motor down until the
cartridge away (down) sensor is detected.
Drive Cartridge Up Selecting this diagnostic function drives the cartridge tilt motor up until the
cartridge home (up) sensor is detected.
Toggle Paste
Dispense
Selecting this diagnostic function alternately applies and removes the air pres-
sure to the paste dispense cartridge, displaying On when air pressure is applied
and Off when air pressure is removed.
Paste Cartridge
Empty
This diagnostic function continuously displays the status of the cartridge empty
sensor.
Cartridge in Down
Position
This diagnostic function continuously displays the status of the cartridge away
(down) sensor.
Paste Cartridge Empty
Cartridge in Down Position
Cartridge in Up Position
OFF
OFF
Carriage Home
Drive Carriage To Start Position
Drive Carriage To End Position
Drive Cartridge Down
Drive Cartridge Up
Toggle Paste Dispense
Paste Dispense System Diagnostics
ON
ON
Run
Diagnost
Next Previous Exit
