semi automatic ',$*12 67, &6 6&5((1 &/($1 (5 Software Version 07SP02 User Manual 4.25 SCREEN CLEANER Selectin g this diagnos tics modul e opens the fol lowing wi ndow: The menu bar changes to the follow…
semi automatic
',$*1267,&6
6&5((1&+$1*(
4.24 User Manual Software Version 07SP02
SCREEN CHANGE
Selecting this diagnostics module opens the following window:
The menu bar changes to the following:
Next / Previous keys have no function in this application.
Run Diagnost activates the toggle screen clamps diagnostic function.
Exit returns operation to the module diagnostics page.
Toggle Screen
Clamps
Selecting this diagnostic function alternately energizes and de-energizes the
screen clamps, displaying ‘On’ when energized and ‘Off’ when de-energized,
(not used on this machine).
Screen Sensor This diagnostic function continuously displays the status of the screen sensor.
Screen Change Diagnostics
OFF
Toggle Screen Clamps
Screen Sensor
ON
Run
Diagnost
Next Previous Exit
semi automatic
',$*1267,&6
6&5((1&/($1(5
Software Version 07SP02 User Manual 4.25
SCREEN CLEANER
Selecting this diagnostics module opens the following window:
The menu bar changes to the following:
Next / Previous keys move the highlight bar up and down the list of selectable
diagnostic functions.
Run Diagnost activates the diagnostic function, as selected by the highlight
bar.
Exit returns operation to the module diagnostics page.
Adjust opens the following window:
The menu bar changes to the following:
Incr. / Decr. keys change the value of the cycle count.
Exit returns operation to the screen cleaner diagnostics page.
Toggle Dry Wipe
Blade
Selecting this diagnostic function raises and lowers the cleaner body assembly,
displaying On when the cleaner body assembly is raised and Off when the
cleaner body assembly is lowered.
Screen Cleaner Diagnostics
ON
Cleaner Paper Low/Advance
Cleaner Solvent Low
Pinch Valve Fitted
ON
OFF
Toggle Pinch Valve (if fitted)
Toggle Paper Feed
Toggle Vacuum
Toggle Solvent Feed/Tank Press
Toggle Screen Cleaner Home Clamp
Cycle Pinch Valve
Cycle Clean Blade
Toggle Dry Wipe Blade
Cycle Count
Done :-
0, To go :-
50
OFF
OFF
OFF
OFF
ON
ON
OFF
Run
Diagnost
Adjust Next Previous Exit
Cleaner Cycle Parameters
CYCLE COUNT
50.0
Cycles
Incr. Decr. Exit
semi automatic
',$*1267,&6
6&5((1&/($1(5
4.26 User Manual Software Version 07SP02
Toggle Pinch Valve Selecting this diagnostic function alternately energizes and de-energizes the
solvent valve, displaying On when the solvent valve is energized and Off when
the solvent valve is de-energized.
Toggle Paper Feed Selecting this diagnostic function alternately switches the paper feed motor on
and off, displaying its current status.
Toggle Vacuum Selecting this diagnostic function alternately switches the vacuum pump on and
off, displaying its current status.
Toggle Solvent
Feed/Tank
Pressure
Selecting this diagnostic function alternately energizes and de-energizes the
solvent tank pressure solenoid, displaying On when air pressure is switched to
the tank and Off when air pressure is removed.
Toggle Screen
Cleaner Home
Clamp
Selecting this diagnostic function alternately energizes and de-energizes the
screen cleaner home clamp electromagnet, displaying its status.
Cycle Pinch Valve Selecting this diagnostic function continuously opens and closes the solvent
valve for the number of cycles specified in the cycle count.
Cycle Clean Blade Selecting this diagnostic function continuously raises and lowers the cleaner
body assembly for the number of cycles specified in the cycle count.
Cleaner Paper
Low/Advance
This diagnostic function continuously displays the status of the cleaner paper
low/advance sensor.
Cleaner Solvent
Low
This diagnostic function continuously displays the status of the cleaner solvent
low sensor.
Pinch Valve Fitted This diagnostic function continuously displays the status of the solvent valve.
Cycle Count This diagnostic function displays the amount of cycles done and the amount of
cycles to go to complete the cycle count.
