Software Version 07SP02 User Manual 6.3
SET TIME
The Set Time option allows the user to set the current time on the machine.
On selecting Set Time the following window is displayed:
The menu bar changes to the following:
The Next and Previous keys move the cursor between the three parameters.
The Incr. and Decr. keys change the value of the highlighted parameter.
The Set key sets the newly entered figure, as shown in the title window on the
status page.
The Exit key returns to the previous menu. Pressing Exit without pressing Set
returns the machine to the previous time.
Change time page
Hour
Minute
Second
:15
:25
:45
Set Next Previous Incr. Decr. Exit
semi automatic
+286(.((3,1*
35,17'$7$
6.4 User Manual Software Version 07SP02
PRINT DATA
The Print Data option allows the user to output the following data to the local
printer (printer port located on the rear panel of the PC) or to a disk in the
machines floppy drive:
On selecting Print Data the following window is displayed:
The menu bar changes to the following:
The Print Printer key prints the chosen file to the local printer, if Product Data
is highlighted a further window and menu bar open to allow the user to select
the required product data file (see next page).
The Print File key outputs the print file to the machines floppy drive, the file has
a .PRN extension. If Product Data is highlighted a further window and menu
bar open to allow the user to select the required product data file (see next
page).
The Up and Down keys move the cursor between the data file types.
The Exit key returns to the previous menu bar.
Data Option File Output (as .PRN files)
Product Data Chosen Product Data File
Config Data CONFIG.TXT
Manage Data MANINF.DAT
SPC Data READINGS.DEK
Print Data
Print From: Local Drive
Drive
Product Data
Config File
Management
SPC Data
Print
Printer
Print
File
Up Down Exit
semi automatic
+286(.((3,1*
35,17'$7$
Software Version 07SP02 User Manual 6.5
If the Print Printer or Print File keys are pressed when Product Data is
highlighted the following window is displayed:
The menu bar changes to the following:
The Left and Right keys move between columns (if displayed).
The Up and Down keys move vertically through the files.
Exit returns to the housekeeping display without any other action.
Print Printer outputs the Product File to the local printer.
Print File outputs the Product File to the machines floppy drive, the file has a
.PRN extension.
Print Data File
Search
265TEST1
Product ID
265TEST1-
265TEST1
CALIBRA
DEFAULT
Print
Printer
Print
Data
Left Right Up Down Exit
