6.8 User Manual Software Version 07SP02
If the Copy Data key is pressed when Image Data is highlighted, the following
window is displayed:
The menu bar changes to the following:
The Copy File key copies the selected product data file from the source to the
destination.
The Left and Right keys move the cursor between product file columns (if
displayed).
The Up and Down keys move the cursor between the various product data files.
The Exit key returns to the previous menu.
If the Copy All key is pressed when Product data is highlighted, the message
‘Do you also want to create a copy of the inspection data associated with
each process program that is to be copied?’ is displayed. The menu bar
changes to the following:
The Yes key copies all the highlighted product data files between the drives as
indicated, with all the inspection data that is associated with it. The message
‘Copying All Files Please Wait’ is displayed.
The No key copies all the highlighted product data files between the drives as
indicated, without the inspection data that is associated with it. The message
‘Copying All Files Please Wait’ is displayed.
Copy Data File
Insp0000
Insp0001
Insp0002
Insp0003
Insp0004
Insp0005
Copy
File
Left Right Up Down Exit
Yes No
semi automatic
+286(.((3,1*
'(/(7('$7$
Software Version 07SP02 User Manual 6.9
DELETE DATA
The Delete Data function allows the operator to delete various data types.
On selecting the Delete Data key the following window is displayed:
NOTE
Deviation Data is not available on this machine.
The menu bar changes to the following:
The Up and Down keys move the cursor through the data types.
The function of the Delete Data option depends on the type of data selected,
the options are:
Product Data; Test Data; SPC Data; Image Data
Product Data If the Delete Data key is pressed when Product Data is highlighted the following
window is displayed:
Drive
Delete From: Local Drive
Delete Data
Product Data
Test Data
SPC Data
Config Data
Service Data
Deviation Data
Image Data
Delete
Data
Up Down Exit
Delete Data File
265TEST1
CALIBRA
DEFAULT
Search
265TEST1
Product ID
265TEST1-
semi automatic
+286(.((3,1*
'(/(7('$7$
6.10 User Manual Software Version 07SP02
The menu bar changes to the following:
The Left and Right keys move the cursor between columns of Product Data
Files.
The Up and Down keys move the cursor between the Product Data Files.
The Exit key returns to the previous menu.
On pressing the Delete key, the message ‘Confirm deletion of selected
product data’ is displayed in the message prompt box, asking the user to
confirm the deletion request, the menu bar changes displaying the ‘Yes’ and
‘No’ options:
Test Data If the Delete Data key is pressed when Test Data is highlighted, the message
‘Confirm deletion of Test Data’ is displayed in the message prompt box,
asking the user to confirm the deletion request, the menu bar changes display-
ing the ‘Yes’ and ‘No’ options.
SPC Data If the Delete Data key is pressed when SPC Data is highlighted, the message
‘Confirm deletion of SPC Data’ is displayed in the message prompt box,
asking the user to confirm the deletion request, the menu bar changes display-
ing the ‘Yes’ and ‘No’ options.
Image Data If the Delete Data key is pressed when Image Data is highlighted the following
window is displayed:
Delete Left Right Up Down Exit
Yes No
Yes No
Yes No
Delete Data File
10000001
10000002
10000003
10000004
10000005
10000006
