7.18 User Manual Software Version 07SP02
2. Enter parameters using the Next, Previous, Incr. and Decr. keys. A coarse
set of values is shown above
3. Select Limit Options.
This is usually set to enabled. If the global limit option is disabled, the limit
set and parameter is greyed out. This is a limit set option, therefore it is only
active for this particular limit set. If paste inspection is not required for the
whole product, this can be achieved in global limit options under edit globals,
earlier in this chapter.
4. Enter limit set options using Next, Previous, Incr. and Decr. keys.
5. Select Exit.
6. Select Save Limits. The message ‘Saving Fiducial Data - Please Wait
Board data file saved’ is displayed.
7. Select Exit.
Limit
Options
Save
Limits
Next Previous Incr. Decr. Exit
Limit
Options
Save
Limits
Next Previous Incr. Decr. Exit
Site Limit Set Options
Paste Enabled
Next Previous Incr. Decr. Exit
Next Previous Incr. Decr. Exit
Limit
Options
Save
Limits
Next Previous Incr. Decr. Exit
Add
Limits
Edit
Limits
Next
Limit
Previous
Limit
Exit
semi automatic
',163(&7,21
',163(&7,216(783
Software Version 07SP02 User Manual 7.19
Selecting an
Existing Site
To edit an existing site carry out one of the following procedures:
• Using the mouse left button, select the position of the site on the represen-
tation of the board.
• Using the mouse left button, select the site (or device) name on the devices
and site list.
• Use the Next / Previous buttons on the menu bar.
When an existing site is selected the following GUI display information is
updated:
• Site parameter information.
• Site X and Y coordinates.
• Vision panel camera display image of new site.
semi automatic
',163(&7,21
',163(&7,216(783
7.20 User Manual Software Version 07SP02
How to Add a Site The following procedure details a typical example of creating a new site with the
GUI board representation displaying the default standard board size format.
NOTE
It may be an advantage to have a board at hand in order to roughly estimate
required site locations.
1. Roughly position the camera to a desired site using the mouse controls and
click on the desired area of the monitor board representation.
2. A camera icon appears at the area selected. The machine camera moves
to the selected area (and board and stencil features are displayed in the
vision window).
3. To position the camera more accurately to the required inspection site,
adjust the X and Y scroll bars displayed in the vision window.
4. Select Add Site.
The site name is automatically appended to a default name, ie SITE001.
If an existing site is selected the menu bar also includes Delete, Edit and
Inspect site function buttons.
NOTE
The operator can rename the new site as required by selecting Incr. or Decr.
and using the keyboard. Press Enter on completion.
Edit
Global
Edit
Limits
Add
Site
Exit
