semi automatic
&21680$%/(5(3/(1,6+0(176
,1752'8&7,21
Software Version 07SP02 User Manual 8.1
CHAPTER 8 CONSUMABLE REPLENISHMENTS
INTRODUCTION
This chapter describes the general replenishment processes needed for
machine husbandry. It details the procedures needed to perform the following
tasks:
• Solder paste replenishment
• Paper and solvent replenishment of the underscreen cleaner
• Cleaning cassette and solvent replenishment - Vortex USC
• Filter cassette replenishment - Vortex USC
• Fitment of squeegees
• ProFlow - paste cassette change
• ProFlow - paste retention system replacement
• ProFlow - transfer head recharging
Regulations The safety and environmental aspects of machine operation are described.
However, it should be noted that local or national regulations may vary for
countries outside the UK or EEC. Machine operatives should be conversant
with all regulations relating to local conditions.
Competence Level These procedures can only be performed by personnel who have been trained
to a minimum of DEK operator level.
semi automatic
&21680$%/(5(3/(1,6+0(176
3$67(/2$',1*
8.2 User Manual Software Version 07SP02
PASTE LOADING
Two options are provided for loading paste onto the screen, Manual Load and
Auto Dispense. Manual load allows the operator to load paste by hand onto
the stencil. Auto dispense loads paste automatically onto the stencil in the
correct area, from the paste cartridge located in the paste dispenser on the print
carriage. Auto dispense can be programmed into a product file to take place
automatically during a print run or either option can be selected, directly from
the MMI, to take place at the operators discretion.
The print direction option allows the user to select the direction of the next print
stroke after paste loading. The option is available prior to pressing Run in all
machine modes, ie Auto/Single/Stop.
WARNING
SOLDER PASTE AND SOLVENTS. WHEN USING OR HANDLING ANY SOLDER
PASTE OR SOLVENT FORMULATION THE MANUFACTURERS’ RECOMMEND
SAFETY PRECAUTIONS MUST BE STRICTLY ADHERED TO.
WARNING
PROTECTIVE CLOTHING. APPROVED PROTECTIVE CLOTHING SHOULD BE
WORN BY SOLDER PASTE AND SOLVENT HANDLERS AT ALL TIMES TO
ELIMINATE FUME INHALATION, EYE CONTACT, SKIN CONTACT AND
INGESTION.
Manual Loading
Paste
Replenishment Off
NOTE
With the Paste Dispenser not fitted, the paste dispense rate (in the product file)
pauses the machine after printing the amount of boards specified. This allows
the operator to open the printhead to load paste on to the stencil. The paste
dispense rate can be set from 1 to 100 boards. If 0 (zero) is entered, the
operator is not be reminded to replenish the paste.
1. Press Paste Load (F3).
2. Press Manual Load (F2). The message ‘Open cover and load paste’ is
displayed.
3. Raise the printhead cover.
Run
Open
Cover
Paste
Load
Clean
screen
Setup Monitor Maint.
Auto
Dispense
Manual
Load
Load
Cart.
Print
Directn
Exit
semi automatic
&21680$%/(5(3/(1,6+0(176
3$67(/2$',1*
Software Version 07SP02 User Manual 8.3
4. Load the solder paste onto the screen.
5. Lower the printhead cover.
6. Press the System button.
7. Press Continue (F1).
8. Press Exit (F8).
Paste
Replenishment On
NOTE
With the Paste Dispenser not fitted, the paste dispense rate (in the product file)
pauses the machine after printing the amount of boards specified. This allows
the operator to open the printhead to load paste on to the stencil. The paste
dispense rate can be set from 1 to 100 boards. If 0 (zero) is entered, the
operator is not be reminded to replenish the paste.
1. When the machine has printed the amount of boards specified in the Paste
Dispense Rate setting, the machine is stopped and the message ‘Open
cover and load paste’ is displayed in the Message Prompt Window of the
MMI. The following menu bar is displayed.
NOTE
Selecting the Continue (F1) button restarts the printing without the oppor-
tunity to replenish the paste.
2. Raise the printhead cover.
3. Load the solder paste onto the stencil.
4. Lower the printhead cover.
5. Press the System button.
Continue
Auto
Dispense
Manual
Load
Load
Cart.
Print
Directn
Exit
Continue
