1.72 User Manual Software Version 07SP02
MENU PARAMETERS
Each product has a set of parameters which are unique to that particular product
and which need to be setup to obtain acceptable printing results. These
parameters are listed below with a definition of each as an aid to machine setup.
Product Name The file name for the particular product. The name can consist of up to eight
alphanumeric characters with no punctuation.
Product ID The product ID is a parameter that allows a description of the product. This
string may be up to 32 characters long, but only the first 20 characters are
displayed.
Image Detail This parameter allows the user to modify the stencil image data of the selected
screen library file. Once selected, pressing Incr. or Decr. Keys opens the Image
Detail Configuration page.
NOTE
This parameter is only displayed, if Screen Size in Set Preferences has been
selected to Screen Library.
Mesh Front This parameter sets the distance between the inner edge of the stencil frame
and the stencil glue line at the front of the frame. It defines the area that should
not be contacted by the squeegees/ProFlow.
Mesh Rear This parameter sets the distance between the inner edge of the stencil frame
and the stencil glue line at the rear of the frame. It defines the area that should
not be contacted by the squeegees/ProFlow.
Mesh Left This parameter sets the distance between the inner edge of the stencil frame
and the stencil glue line at the left of the frame. It defines the area that should
not be contacted by the squeegees/ProFlow.
Mesh Right This parameter sets the distance between the inner edge of the stencil frame
and the stencil glue line at the right of the frame. It defines the area that should
not be contacted by the squeegees/ProFlow.
Minimum Maximum Increment Default
0.0mm Screen Length - 250.0mm 0.1mm 38.0mm
Minimum Maximum Increment Default
0.0mm Screen Length - 250.0mm 0.1mm 38.0mm
Minimum Maximum Increment Default
0.0mm Screen Width - 250.0mm 0.1mm 38.0mm
Minimum Maximum Increment Default
0.0mm Screen Width - 250.0mm 0.1mm 38.0mm
semi automatic
0$&+,1(352*5$00,1*
0(183$5$0(7(56
Software Version 07SP02 User Manual 1.73
Image X This parameter defines the dimension in the X axis from the right inner edge of
the stencil frame to either:
Right hand edge of the image - right justified image
Left hand edge of the image - left justified image
Centre line of the image - centre justified image
Image Y This parameter defines the dimension in the Y axis from the front inner edge of
the stencil frame to either:
Front edge of the image - front justified image
Rear edge of the image - rear justified image
Centre line of the image - centre justified image
Image X
Justification
This parameter defines the position of the image about the Image X parameter.
The image can be left, right or centre justified about Image X. Options are:
Image Y
Justification
This parameter defines the position of the image about the Image Y parameter.
The image can be front, rear or centre justified about Image Y. Options are:
Minimum Maximum Increment Default
60.0mm Screen Length - 100.0mm 0.1mm 330.4mm
Minimum Maximum Increment Default
60.0mm Screen Width - 100.0mm 0.1mm 330.4mm
Option Default
Left Centre
Right
Centre
Option Default
Front Centre
Rear
Centre
semi automatic
0$&+,1(352*5$00,1*
0(183$5$0(7(56
1.74 User Manual Software Version 07SP02
Screen Adapter The type of screen adapter needed, if any, for the stencil to be used for this
product.
NOTE
This parameter is not displayed, if Screen Size in Set Preferences has been
selected to Screen Library.
Screen Image The position of the image in the stencil frame. Options are:
NOTE
This parameter is not displayed, if Screen Size in Set Preferences has been
selected to Screen Library.
Custom Screen This option allows user definable stencil image positions. Selection of this
parameter activates the Print Area Length, Print Area Width and Distance To
Image. Options are:
NOTE
This parameter is not displayed, if Screen Size in Set Preferences has been
selected to Screen Library.
Distance to Image The meaning of this parameter varies, depending on whether an image is centre
or edge justified. For centre justified images, the dimension is the distance from
the outside rear of the stencil frame to the centre of the image. For edge justified
images, the dimension is the distance from the outside rear of the stencil frame
to the front edge of the board.
NOTE
This parameter field only appears if Custom Screen has been selected.
Options Available
None
255
Sanyo
Heraeus
20 X 20
12 X 12
Options Available Notes
Edge Justified Permitted for Sanyo and Fuji frames only
Centre Justified -
Options Available
Enabled
Disabled
Minimum Maximum Increment
306.0mm 645.0mm 0.1mm
