Software Version 07SP02 User Manual 1.73
Image X This parameter defines the dimension in the X axis from the right inner edge of
the stencil frame to either:
Right hand edge of the image - right justified image
Left hand edge of the image - left justified image
Centre line of the image - centre justified image
Image Y This parameter defines the dimension in the Y axis from the front inner edge of
the stencil frame to either:
Front edge of the image - front justified image
Rear edge of the image - rear justified image
Centre line of the image - centre justified image
Image X
Justification
This parameter defines the position of the image about the Image X parameter.
The image can be left, right or centre justified about Image X. Options are:
Image Y
Justification
This parameter defines the position of the image about the Image Y parameter.
The image can be front, rear or centre justified about Image Y. Options are:
Minimum Maximum Increment Default
60.0mm Screen Length - 100.0mm 0.1mm 330.4mm
Minimum Maximum Increment Default
60.0mm Screen Width - 100.0mm 0.1mm 330.4mm
Option Default
Left Centre
Right
Centre
Option Default
Front Centre
Rear
Centre
semi automatic
0$&+,1(352*5$00,1*
0(183$5$0(7(56
1.74 User Manual Software Version 07SP02
Screen Adapter The type of screen adapter needed, if any, for the stencil to be used for this
product.
NOTE
This parameter is not displayed, if Screen Size in Set Preferences has been
selected to Screen Library.
Screen Image The position of the image in the stencil frame. Options are:
NOTE
This parameter is not displayed, if Screen Size in Set Preferences has been
selected to Screen Library.
Custom Screen This option allows user definable stencil image positions. Selection of this
parameter activates the Print Area Length, Print Area Width and Distance To
Image. Options are:
NOTE
This parameter is not displayed, if Screen Size in Set Preferences has been
selected to Screen Library.
Distance to Image The meaning of this parameter varies, depending on whether an image is centre
or edge justified. For centre justified images, the dimension is the distance from
the outside rear of the stencil frame to the centre of the image. For edge justified
images, the dimension is the distance from the outside rear of the stencil frame
to the front edge of the board.
NOTE
This parameter field only appears if Custom Screen has been selected.
Options Available
None
255
Sanyo
Heraeus
20 X 20
12 X 12
Options Available Notes
Edge Justified Permitted for Sanyo and Fuji frames only
Centre Justified -
Options Available
Enabled
Disabled
Minimum Maximum Increment
306.0mm 645.0mm 0.1mm
semi automatic
0$&+,1(352*5$00,1*
0(183$5$0(7(56
Software Version 07SP02 User Manual 1.75
Print Area Length This is the maximum printable distance in the Y direction, ie the maximum
distance the squeegee can travel, front to back.
NOTE
This parameter field only appears if Custom Screen has been selected.
Print Area Width This is the maximum length of squeegee that could be fitted to the printer, taking
into account stencil frame and the amount of mesh surrounding the mask. This
is also the maximum length of paste that can be dispensed.
NOTE
This parameter field only appears if Custom Screen has been selected.
Board Width This parameter sets the rail width for this particular product. It is also used to
set a default value for the print stroke, the clean screen and the board stop
position in the Y direction. The maximum value depends on the stencil type
selected.
Board Length This parameter is used to set the default values for the board stop position in
the X direction, and the paste dispensing area. The maximum value depends
on the type of stencil selected.
Minimum Maximum Increment
100.0mm 508.5mm 0.1mm
Minimum Maximum Increment
100.0mm 510.0mm 0.1mm
Minimum Maximum Increment
40.0mm 265 508.0mm 0.1mm
255 432.0mm
249 330.0mm
Fuji 460.0mm
Sanyo 284.0mm
Heraeus 344.0mm
Minimum Maximum Increment
50.0mm 265 510.0mm 0.1mm
255 460.0mm
249 430.0mm
Fuji 460.0mm
Sanyo 420.0mm
Heraeus 344.0mm
