1.84 User Manual Software Version 07SP02
ProFlow Cassette This parameter sets the size of the transfer head used by the ProFlow unit. Size
may be one of the following:
NOTE
For 350mm and 450mm transfer heads, set to 400mm and 500mm respectively.
ProFlow System
Pressure
This is the amount of print pressure (downward force) applied onto the stencil
by the ProFlow unit.
Board 1 Fiducial
Type
This determines the type of model to be used for this fiducial. Options are:
Board 2 Fiducial
Type
This determines the type of model to be used for this fiducial. Options are:
Size
300.0mm
400.0mm
500.0mm
Minimum Maximum Increment Default
0.0Kg 20.0Kg 0.2Kg 0.0Kg
Model Option Note
Circle
See vision system
Rectangle
Diamond
Triangle
Double Square
Cross
Video Model
Model Option Note
Circle
See vision system
Rectangle
Diamond
Triangle
Double Square
Cross
Video Model
semi automatic
0$&+,1(352*5$00,1*
0(183$5$0(7(56
Software Version 07SP02 User Manual 1.85
Screen 1 Fiducial
Type
This determines the type of model to be used for this fiducial. Options are:
Screen 2 Fiducial
Type
This determines the type of model to be used for this fiducial. Options are:
Fiducial 1 X
Coordinate
Distance of first fiducial from the right or left hand edge of the board (configura-
tion dependent).
If the current product includes at least one inspection site, changing the value
of the parameter causes the following warning and menu bar to be displayed:
On selecting Apply the alterations to the fiducial positions become effective and
are applied to all inspection sites.
On selecting Abandon Changes the alterations to the fiducial positions are
discarded, the positions of the inspection sites remain unaltered and control is
returned to the initiating sequence.
On selecting Don’t Apply the alterations to the fiducial positions become
effective, but are not applied to the inspection sites.
Model Option Note
Circle
See vision system
Rectangle
Diamond
Triangle
Double Square
Cross
Video Model
Model Option Note
Circle
See vision system
Rectangle
Diamond
Triangle
Double Square
Cross
Video Model
Minimum Maximum Increment Default
1.0mm Board Length 0.1mm 1.0mm
Warning
From the changes made to fiducial positions
do you want a correction to be applied to
all inspection sites?
Apply
Abandon
Changes
Don’t
Apply
semi automatic
0$&+,1(352*5$00,1*
0(183$5$0(7(56
1.86 User Manual Software Version 07SP02
Fiducial 1 Y
Coordinate
Distance of first fiducial from the front edge of the board.
NOTE
Refer to Fiducial 1 X Coordinate warning window information.
Fiducial 2 X
Coordinate
Distance of second fiducial from the right or left hand edge of the board
(configuration dependent).
NOTE
Refer to Fiducial 1 X Coordinate warning window information.
Fiducial 2 Y
Coordinate
Distance of the second fiducial from the front edge of the board.
NOTE
Refer to Fiducial 1 X Coordinate warning window information.
Forward X Offset Programmable offset of the print on the board when printing from the rear.
A positive offset moves the print to the right of the board.
Forward Y Offset Programmable offset of the print on the board when printing from the rear.
A positive offset moves the print to the rear of the board.
Forward Theta
Offset
Programmable offset of the print on the board when printing from the rear.
A positive offset moves the print in a clockwise direction.
Reverse X Offset Programmable offset of the print on the board when printing from the front.
A positive offset moves the print to the right of the board.
Minimum Maximum Increment Default
1.0mm Board Width 0.1mm 1.0mm
Minimum Maximum Increment Default
1.0mm Board Length 0.1mm 1.0mm
Minimum Maximum Increment Default
1.0mm Board Width 0.1mm 1.0mm
Minimum Maximum Increment
-1.0mm +1.0mm 0.004mm
Minimum Maximum Increment
-1.0mm +1.0mm 0.004mm
Minimum Maximum Increment
-1000 arc seconds +1000 arc seconds 2 arc seconds
Minimum Maximum Increment
-1.0mm +1.0mm 0.004mm
