semi automatic
0$&+,1(352*5$00,1*
0(183$5$0(7(56
1.88 User Manual Software Version 07SP02
Separation
Vacuum Delay
This parameter determines the duration of vacuum applied after printing and
before the rising table is lowered to separation height with Vac for Flex enabled.
Tooling Deviation This parameter sets the extent of tooling deviation before a warning message
is posted.
Board Stop X This parameter determines the distance from the centre line of the machine to
the board stop position.
Board Stop Y This parameter determines the distance from the fixed rail to the board stop
position.
Paste Start This parameter determines start position of the paste dispense measured from
the centre line of the machine. The limits depend on the type of stencil fitted.
Minimum Maximum Increment Default
0 sec 5 secs 0.1 sec 2 secs
Minimum Maximum Increment Default
0% 50% 0.25% 20%
Minimum Maximum Increment Default
0.0mm 255.0mm 0.1mm Half of the board
length set in the board
file, (board located
centrally)
Minimum Maximum Increment Default
20.0mm Board width minus
15.0mm
0.1mm Two thirds of the
board width
Minimum Maximum
Adapter Start Position Adapter Start Position
No Adapter -255.0mm No Adapter +255.0mm
255 -230.0mm 255 +230.0mm
Sanyo -210.0mm Sanyo +210.0mm
Heraeus -172.0mm Heraeus +172.0mm
249 -215.0mm 249 +215.0mm
Default - half the board length Default + half the board length
semi automatic
0$&+,1(352*5$00,1*
0(183$5$0(7(56
Software Version 07SP02 User Manual 1.89
Paste Stop This parameter determines stop position of the paste dispense measured from
the centre line of the machine. The maximum value depends on the type of
stencil fitted.
SPC Configuration This preference allows the user to set up the Machines SPC operation. On
selecting the SPC Configuration by pressing the Incr. or Decr. buttons, a window
opens and the menu bar changes.
NOTE
See the SPC Configuration section in this chapter for further details.
Minimum Maximum
Adapter Start Position Adapter Start Position
No Adapter -255.0mm No Adapter +255.0mm
255 -230.0mm 255 +230.0mm
Sanyo -210.0mm Sanyo +210.0mm
Heraeus -172.0mm Heraeus +172.0mm
249 -215.0mm 249 +215.0mm
Default - half the board length Default + half the board length
semi automatic
0$&+,1(352*5$00,1*
63&&21),*85$7,21
1.90 User Manual Software Version 07SP02
SPC CONFIGURATION
When the cursor on the Edit Current Process Parameters page highlights the
SPC Configuration option and Incr. or Decr. are pressed an SPC Configuration
Window opens and two extra menu options become available:
Configuration
Window
The configuration window allows the user to setup the machines SPC operation.
Data Output Rate Two rates of data output are available as follows:
Every Cycle - Outputs SPC data every cycle except for the camera data, which
is output dependant upon the settings of the parameters start rate, sample rate
and start rate limit.
On Inspect - Outputs all SPC data at a rate dependant upon the settings of the
parameters start rate, sample rate and start rate limit.
Start Rate Limit Sets the amount of SPC output cycles at the start rate. When this limit is
reached the sample rate parameter becomes the active SPC output rate. The
range is 0-100, where 0 = continuous SPC output at the start rate.
NOTE
Setting both start rate limit and sample rate to zero causes continuous SPC
output at the start rate.
Start Rate Sets the initial SPC output rate, for setting up a line. If start rate is set to 10,
SPC data is output every 10 cycles until the start rate limit is reached, when the
rate becomes that set in the sample rate parameter. The range is 1-100.
Sample Rate Sets the rate of SPC output after the start rate limit has been reached. The
range is 0-100, where 0 = continuous SPC outputs at start rate. If sample rate
is set to 15, SPC data is output every 15 cycles after the start rate limit is
reached.
Edit
Outputs
Edit
Limits
Next Previous Incr. Decr. Exit
SPC Configuration Page
DATA OUTPUT RATE
START RATE
SAMPLE RATE
START RATE LIMIT
SPC DATA MODE
SPC FORMAT
UPDATE ON START-UP
ALIGN INSPECT MODE
EVERY CYCLE
1
10
10
NONE
WINDOWS
NO
PRE PRINT
cycles
cycles
cycles
