2.11 Energy State After Switching off Main Switch From software version SC.708.0 Edition 12/2014 EN -DRAFT
112
The following table specifies the voltages of modules when the machine is switched off at the main
switch, but still connected to the mains supply.
2
Module Voltage
Terminal panel X100
Mains filter Z1
Terminals L1, L2, L3
3 x 208 VAC
3 x 230 VAC
3 x 380 VAC
3 x 400 VAC
3 x 415 VAC
Service socket X102
120 VAC
130 VAC
220 VAC
230 VAC
240 VAC
Automatic circuit breaker F1
120 VAC
130 VAC
220 VAC
230 VAC
240 VAC
Main switch Q1
Terminals L1, L2, L3
3 x 208 VAC
3 x 230 VAC
3 x 380 VAC
3 x 400 VAC
3 x 415 VAC
Main switch Q1
Terminals T1, T2, T3
0 VAC
Power supply unit
(see item 5 of fig. 2.9 - 2
)
Test socketX11
GNDX12
Test socketX13_1
Test socketX13_4
GNDX13_7
< 10 VDC
< 10 VDC
< 10 VDC
Computer unit (see fig. 2.11 - 3
)
Test socket+ 12 VDC
Test socket- 12 VDC
Test socket+ 15 VDC
Test socket-15 VDC
Test socket+ 5 VDC
Test socket+ 52 VDC
Test socket+ 3.3 VDC
GND
0 VDC
0 VDC
0 VDC
0 VDC
0 VDC
0 VDC
0 VDC
User Manual SIPLACE CA-Series 2 Operational Safety
From software version SC.708.0 Edition 12/2014 EN -DRAFT 2.11 Energy State After Switching off Main Switch
113
2.11.1.2 Machine Switched off at Main Switch and Disconnected From Power
The machine is unpowered, apart from slight residual voltages in the power supply unit.
The SWS must be separately disconnected from the mains power supply!
2.11.1.3 Compressed Air Conditions in the Machine After Switching off at the Main
Power Switch
When you switch off the main switch (item 1 in fig. 2.11 - 1, page ) or if the power supply to the
machine fails, the electrically controlled main valve Y1 of the compressed air unit will be closed
(item 1 in fig. 2.10 - 1
). The pressure will drop to 0 MPa (0 bar) within 5 seconds.
2.11.2 Main Switch at the SWS
Each SWS has its own main switch for the voltage supply.
2 Operational Safety User Manual SIPLACE CA-Series
2.12 Lock Out and Tag Out Procedure From software version SC.708.0 Edition 12/2014 EN -DRAFT
114
2.12 Lock Out and Tag Out Procedure
2
2.12.1 Purpose and Scope
Before performing any preventive maintenance work or service work, a procedure of locking and
tagging must be followed. The procedure, when followed correctly eliminates the possibility of an
employee being injured.
2
2.12.2 Description
Whenever it becomes necessary to isolate, control and release energy, the following procedure is
to be followed
Notify affected employees.
Shut down the equipment. Carry out all normal stopping procedures:
– Press the stop button.
– Shut down the control computer.
– Switch the machine off at the main power switch.
Isolate the machine from all its energy sources:
– Shut off the compressed air supply
– Shut off the main power supply
Lock the machine, including the SWS.
– Attach a lock whenever possible, e.g. to the motor contactor.
CAUTION
The following instructions also apply to the SWS modules.
PLEASE NOTE
Minimum requirements
These procedures represent the minimum lock/tag out requirements for the preventive
maintenance or service work. Any additional safeguards needed to complete work safely
can be specified by facilities supervision, the safety officer, the safety committee and the
health department.
