3.1.3 Technical Data - SMT
3
Placement head types SIPLACE SpeedStar (C&P20 M)
SIPLACE MultiStar (CPP)
SIPLACE TwinStar (TH)
Number of gantries CA4: 4 gantries
Component range 0.4 x 0.2 mm² (01005), 0.6 x 0.3 mm² (0201)
to 85 x 85 mm² / 125 x 10 mm²,
Max. 200 x 125 mm² (with restrictions)
Component height C&P20 M
CPP
TH
4 mm
6 mm / 8.5 mm / 11.5 mm
25 mm (greater height on request)
Placement accuracy
(Standard-criteria for
SMD)
C&P20 M
CPP
CPP
TH
TH
± 20 µm (3σ)
± 41 µm (3σ)
± 34 µm (3σ)
± 26 µm (3σ)
± 22 µm (3σ)
Component camera, type 41
Component camera, type 30
Component camera, type 33
Component camera, type 33
Component camera, type 25
Placement accuracy
(Advanced criteria for
SWS)
C&P20 M
CPP
TH
± 10 µm (3σ)
± 41 µm (3σ)
± 26 µm (3σ)
Component camera, type 41
Component camera, type 30
Component camera, type 33
Angular accuracy C&P20 M
CPP
*a
CPP
*b
CPP
TH
TH
± 0.2° (3σ)
± 0.4° (3σ)
± 0.5° (3σ)
± 0.2° (3σ)
± 0.05° (3σ)
± 0.05° (3σ)
Component camera, type 41
Component camera, type 30
Component camera, type 30
Component camera, type 33
Component camera, type 33
Component camera, type 25
*)a Component dimensions between 6 mm x 6 mm and 27 mm x 27 mm.
*)b Component dimensions smaller than 6 mm x 6 mm.
User Manual SIPLACE CA-Series 3 Technical Data
From software version SC.708.0 Edition 12/2014 EN -DRAFT 3.2 Component Feeding
125
3.2 Component Feeding
3
Component feed-
ing
– SIPLACE CA4: Up to four SWS possible in placement area 1 and 2
– Component trolley (X-Series)
(with tape reel mount and integrated waste tape bin,
40 locations a 8 mm X-feeder module per component trolley)
– Matrix Tray Changer (on request)
Feeder module
types
– X-Series component trolley> Tapes, waffle pack trays
Supply capacity
(Component trol-
ley
X-Series)
160 tracks Width: 10.8 mm 4 mm X feeder modules
160 tracks Width: 10.8 mm 8 mm X feeder modules
160 tracks Width: 22.9 mm Smart Feeder 2x8 mm X
80 tracks Width: 22.6 mm Smart Feeder 12 mm X
52 tracks Width: 22.6 mm Smart Feeder 16 mm X
52 tracks Width: 34.4 mm 24 mm X feeder modules
40 tracks Width: 46.2 mm 32 mm X feeder modules
32 tracks Width: 58.0 mm 44 mm X feeder modules
24 tracks Width: 69.8 mm 56 mm X feeder modules
20 tracks Width 81.6 mm 72 mm X feeder modules
16 tracks Width: 105.2 mm 88 mm X feeder modules
3 Technical Data User Manual SIPLACE CA-Series
3.3 Ratings for the SIPLACE CA From software version SC.708.0 Edition 12/2014 EN -DRAFT
126
3.3 Ratings for the SIPLACE CA
3.3.1 Electrical Ratings
3
Electrical ratings
Supply voltage 3 x 200 V~ ± 5 %; 50/60 Hz (Japan)
3 x 208 V~ ± 5 %; 50/60 Hz (U.S.A.)
3 x 230 V~ ± 5 %; 50/60 Hz
3 x 380 V~ ± 5 %; 50/60 Hz
3 x 400 V~ ± 5 %; 50/60 Hz (Europe)
3 x 415 V~ ± 5 %; 50/60 Hz
Fuse protection (machine) 3 x 32 A (3 x 200 V~ / 3 x 208 V~ / 3 x 230 V~)
3 x 16 A (3 x 380 V~ / 3 x 400 V~ / 3 x 415 V~)
Mains connection (machine) Cable 5 x 6 mm² with CEKON connector 5 x 32 A (3 x 200 V~ / 208 V~ / 230 V~)
Cable 5 x 4 mm² with CEKON connector 5 x 16 A (3 x 380 V~ / 400 V~ / 415 V~)
Fuse protection (SWS) 3 x 16 A (3 x 208 V~ / 3 x 230 V ~ / 3 x 380 V~ / 3 x 400 V~ / 3 x 415 V~)
Mains connection (SWS)
*a
Cable 4 x 2.5 mm² with CEE connector 5 x 16 A (400 V~)
Nominal apparant power SIPLACE CA4: 4.7 kVA
SWS: 0.7 kVA
Rated current consumption SIPLACE CA4: 11.3 A / 3 x 400 V~
SWS: approx. 1.8 A / 3 x 400 V~
*)a One mains connection required per SWS.
