7 Component and Die Handling User Manual SIPLACE CA-Series 7.1 X Feeder Modules for SIPLACE X-Series From software version SC.708.0 Edition 12/2014 EN -DRAFT 414 7.1.3.2 T echnical Dat a 7 Length 584.9 mm Height 199.5 mm…
User Manual SIPLACE CA-Series 7 Component and Die Handling
From software version SC.708.0 Edition 12/2014 EN -DRAFT 7.1 X Feeder Modules for SIPLACE X-Series
413
7.1.3 SIPLACE Glue Feeder
Item no. 03088129-xx SIPLACE Glue Feeder
7
Fig. 7.1 - 14 SIPLACE Glue Feeder
7.1.3.1 Description
The SIPLACE glue feeder allows you to position dots of adhesive on a component, before it is
placed. These dots of adhesive can then be checked by the SIPLACE Vision system. The required
glue dots can be defined in the Component Shape Editor in SIPLACE Pro and you can also define
whether individual dots of adhesive are to be excluded from inspection or not. This adhesive func-
tion can be enabled and disabled in the Component Editor in SIPLACE Pro. The SIPLACE glue
feeder is a special feeder module which needs to be manually configured as a fixed feature on a
certain table track. For a detailed description. see the "SIPLACE Glue Feeder User Manual, Ger-
man [item no. 00197218-01-xx.],
English [item no. 00197219-xx]
7 Component and Die Handling User Manual SIPLACE CA-Series
7.1 X Feeder Modules for SIPLACE X-Series From software version SC.708.0 Edition 12/2014 EN -DRAFT
414
7.1.3.2 Technical Data
7
Length 584.9 mm
Height 199.5 mm
Width 57.6 mm
Feeder module locations filled 5 tracks, each with
8 mm
Weight 4.6 kg
Diameter of smallest possible individual droplet
*a
*)aat 100 µm nozzle diameter and use of Heraeus PD 205A-Jet glue (at 53°C) or Loctite
3621 (at 53°C)
0.7 - 0.8 mm (+/- 0.1 mm)
Diameter of droplet formed from 5 shots
a
1.0 mm (+/- 0.2 mm)
Height of individual droplets
a
0.15 mm (+/- 0.02 mm)
Height of droplet formed from 5 shots
a
0.2 - 0.3 mm
User Manual SIPLACE CA-Series 7 Component and Die Handling
From software version SC.708.0 Edition 12/2014 EN -DRAFT 7.1 X Feeder Modules for SIPLACE X-Series
415
7.1.4 Linear Dipping Unit X (LDU X)
Item no. 00117011-xx Linear dip module for flux / LDU-X
Item no. Dip plates see section 7.1.4.4
, page 417
7
Fig. 7.1 - 15 Linear Dipping Unit (LDU X)
(1) LDU X
(2) Dip plate
(3) Flux container
(4) Display panel (4 lines each with 20 characters)
(5) Operator panel with 6 membrane keys
(6) LED for status displays
(7) EMERGENCY OFF button
