8.6.3 Technical Data
8.6.3.1 Dimensions, Weight, Other Data
8
Tower 1 (XL) Tower 2
Dimensions
Length x width
Height
1305 x 600 mm²
1560 mm for 900 mm PCB conveyor height
1590 mm for 930 mm PCB conveyor height
1610 mm for 950 mm PCB conveyor height
Weight (basic package) Approx. 500 kg (with cassettes and waffle pack tray carri-
ers)
Weight (fully configured) Approx. 534 kg (with components)
Weight (moving loads) Approx. 80 kg Approx. 43.5 kg
Cassette size (L x W x H) 391.2 x 305.6 x 93.3 mm³ 352.7 x 154.8 x 133.8 mm³
Cassette weight
(fully configured)
(without waffle pack tray carrier)
Approx. 11 kg
Approx. 1.7 kg
Approx. 7.5 kg
Approx. 1.35 kg
Weight of the waffle pack tray carrier 850 g 150 g
Dimensions of waffle pack tray carri-
er (L x W x H) 386.5 x 295.8 x 11.1 mm³ 371 x 146 x 10.1 mm³
Distance from cassette to cassette 96 mm 135 mm
Distance from level to level 12 mm 11.8 mm
Vertical lift
444 mm (1st to 30th WTC
*a
)
511.2 mm (1st to 40th
WTC
a
)
Horizontal lift between transfer and
pickup position Approx. 647 mm Approx. 638 mm
Storage capacity 30 waffle pack tray carrier XL
with 60 JEDEC or
30 special magazines
of maximum size
40 waffle pack tray carriers
with 40 Jedec waffle pack
trays
Changeover time (over 5 levels) Approx. 2 s Approx. 1.5 s
Max. height of component and waffle
pack tray incl. tolerances
All levels occupied
One level free
Two levels free
8.5 mm
19.5 mm
31.5 mm
8.5 mm
19.5 mm
-
*)a Waffle pack tray carrier
8 Station Extensions User manual SIPLACE CA-Series
8.6 Matrix Tray Changer From software version SC.708.0 Edition 12/2014 EN -DRAFT
482
8.6.3.2 Electrical Ratings
8
8.6.3.3 Noise Emissions
8
8.6.3.4 Permissible Environmental Impact
8
Supply voltage 3 x 200 V~ ± 5%; 50/60 Hz (Japan)
3 x 208 V~ ± 5%; 50/60 Hz (U.S.A.)
3 x 400 V~ ± 5%; 50/60 Hz (Europe)
Total output 1.5 kW
Rated current 2.7 A at 3 x 400 VAC
4.2 A at 3 x 208 VAC
Fuse 3 x 16 A
Rated current consumption of largest
consumer
2 A
Max. noise emissions 74 dB (A)
Room temperature Between 15°C and 35°C
Atmospheric humidity 30 - 75 %
(No higher than 45% on average to prevent any pos-
sibility of condensation on the machine)
User manual SIPLACE CA-Series 8 Station Extensions
From software version SC.708.0 Edition 12/2014 EN -DRAFT 8.6 Matrix Tray Changer
483
8.6.4 Installation Notes for the MTC
An MTC can be docked onto locations 2 and 4 of the SIPLACE CA-Series, in place of the compo-
nent trolley.
8
PLEASE NOTE
On request only
– If you want to use an MTC, please contact ASM Assembly Systems GmbH & Co.KG.
