8.7 PCB Barcode Scanner

8.7.1 Overview

[ 8

The PCB barcode reader is used to automatically record and decode barcodes on PCBs. The

PCB barcode scanner sends the read data via its serial interface to the transport controller and

then for further processing to the machine controller via the CAN bus.

Fig. 8.7 - 1 PCB barcode circuit diagram

The PCB barcode scanners are installed on the input side of the placement machine on the PCB

conveyor. Up to four devices can be retrofitted to each machine. The barcode scanners are fitted

[00176117-XX] Cognex DataMan 100X

[00176112-XX] Assembly kit for DataMan X/HS/HF series topside

(for reading barcodes on the topside of the PCB, one per

barcode scanner)

[00176113-XX] Assembly kit for DataMan X/HS/HF series underside

(for reading barcodes on the underside of the PCB, one

per barcode scanner)

[00176118-XX] Cognex I/A module (one per SIPLACE line)

[00176119-XX] Cognex USB cable DM 100 USB (one per SIPLACE line)

[00176120-XX] Wiring for interface I/A box (one per SIPLACE line)

Device number

Bar-

code

scanner

Distribution

board

Transport

controller,

right

Barcode

scanner

under-

Bar-

code

scanner

Distribution

board

Transport

controller,

left

Barcode

scanner

under-

Machine

controller

Station

computer

SIPLACE Pro

computer

LANCAN busV-24V-24

User manual SIPLACE CA-Series 8 Station Extensions

From software version SC.708.0 Edition 12/2014 EN -DRAFT 8.7 PCB Barcode Scanner

487

so that the barcode labels on the topside and underside of the PCBs can be scanned on both

tracks of the dual conveyor.

The barcode scanners are available for 2D codes.

The PCB barcode scanners are fixed to the top and bottom profiled rail using retainers. These can

be positioned as required on the profiled rails, and aligned with respect to the barcode labels. De-

pending on the position of the barcodes, the barcode scanner can be easily assembled so that it

can read the barcodes lengthwise or at right angles to the direction of board transport.

8.7.2 Functions

The PCB barcode scanner supports the flexible manufacture of SMD products, and increases

placement reliability . It recognizes all the code types conventionally used in industrial applica-

tions.

The PCB barcode scanner reads the barcode label on the topside or underside of each incoming

PCB as they are transported onto the input conveyor. Based on the barcode information, the

SIPLACE Pro computer automatically selects the correct placement program from the previously

created barcode allocation list and sends this to the station. If a barcode filter is defined, only in-

formation that is identified as relevant within the barcode is compared. This procedure is carried

out without affecting the time, during placement of the PCB which is already in the machine. If sev-

eral PCBs with the same barcode enter in succession, the program is only transferred the first

time. The following requirements apply to all products to be produced using the PCB barcode:

– The component setup must be identical on all the machines on the line

– All PCBs must be of the same width

8 Station Extensions User manual SIPLACE CA-Series

8.7 PCB Barcode Scanner From software version SC.708.0 Edition 12/2014 EN -DRAFT

488

8.7.3 Technical Data - Cognex DataMan

Code types

2D code types Data Matrix ECC 0, 50, 80, 100, 140, and

200 QR-Code and microQR-Code


Sensor 1/3 inch with global shutter

(resolution 752 x 480)

Picture acquisition Max. 60 fps

Lens type Adjustable lens, 3 positions with (6.2 mm;

F:5 aperture), 40 mm, 65 mm and 105 mm working

distance

I/O

Trigger Fast trigger input, manual trigger key

Trigger voltage -25 V DC to +25 V DC

Trigger current 7.7 mA at 24 VDC

3.7 mA at 12 VDC

1.33 mA at 5 VDC

Trigger delay 1 ms (max)

Discrete inputs 2 opto-isolated (one is used as trigger)

Discrete outputs 2 opto-isolated

Status LEDs 2 Status LEDs (reading LED and communication

LED)

Beeper Programmable functions

Illumination

Illumination Types Integrated bright field lighting with exposure control

Communication

Serial RS-232E

USB Supports USB 2.0 (12 Mbit/s)

Power supply

Power consumption 500 mA at 5 VDC max. (Peak), average.: 300 mA at

5 VDC

Operating voltage 5 V DC to 24 V DC

Mechanics

Material Aluminum housing

Assembly 2 mounting holes M3 x 3.5
