User manual SIPLACE CA-Series 8 Station Extensions
From software version SC.708.0 Edition 12/2014 EN -DRAFT 8.7 PCB Barcode Scanner
487
so that the barcode labels on the topside and underside of the PCBs can be scanned on both
tracks of the dual conveyor.
The barcode scanners are available for 2D codes.
The PCB barcode scanners are fixed to the top and bottom profiled rail using retainers. These can
be positioned as required on the profiled rails, and aligned with respect to the barcode labels. De-
pending on the position of the barcodes, the barcode scanner can be easily assembled so that it
can read the barcodes lengthwise or at right angles to the direction of board transport.
8.7.2 Functions
The PCB barcode scanner supports the flexible manufacture of SMD products, and increases
placement reliability . It recognizes all the code types conventionally used in industrial applica-
tions.
The PCB barcode scanner reads the barcode label on the topside or underside of each incoming
PCB as they are transported onto the input conveyor. Based on the barcode information, the
SIPLACE Pro computer automatically selects the correct placement program from the previously
created barcode allocation list and sends this to the station. If a barcode filter is defined, only in-
formation that is identified as relevant within the barcode is compared. This procedure is carried
out without affecting the time, during placement of the PCB which is already in the machine. If sev-
eral PCBs with the same barcode enter in succession, the program is only transferred the first
time. The following requirements apply to all products to be produced using the PCB barcode:
– The component setup must be identical on all the machines on the line
– All PCBs must be of the same width
8 Station Extensions User manual SIPLACE CA-Series
8.7 PCB Barcode Scanner From software version SC.708.0 Edition 12/2014 EN -DRAFT
488
8.7.3 Technical Data - Cognex DataMan
8
Code types
2D code types Data Matrix ECC 0, 50, 80, 100, 140, and
200 QR-Code and microQR-Code
Sensor 1/3 inch with global shutter
(resolution 752 x 480)
Picture acquisition Max. 60 fps
Lens type Adjustable lens, 3 positions with (6.2 mm;
F:5 aperture), 40 mm, 65 mm and 105 mm working
distance
I/O
Trigger Fast trigger input, manual trigger key
Trigger voltage -25 V DC to +25 V DC
Trigger current 7.7 mA at 24 VDC
3.7 mA at 12 VDC
1.33 mA at 5 VDC
Trigger delay 1 ms (max)
Discrete inputs 2 opto-isolated (one is used as trigger)
Discrete outputs 2 opto-isolated
Status LEDs 2 Status LEDs (reading LED and communication
LED)
Beeper Programmable functions
Illumination
Illumination Types Integrated bright field lighting with exposure control
Communication
Serial RS-232E
USB Supports USB 2.0 (12 Mbit/s)
Power supply
Power consumption 500 mA at 5 VDC max. (Peak), average.: 300 mA at
5 VDC
Operating voltage 5 V DC to 24 V DC
Mechanics
Material Aluminum housing
Assembly 2 mounting holes M3 x 3.5
User manual SIPLACE CA-Series 8 Station Extensions
From software version SC.708.0 Edition 12/2014 EN -DRAFT 8.7 PCB Barcode Scanner
489
8
8
8
8
8
8
8
Dimensions 55 mm x 42 mm x 22 mm
(2.17 inch x 1.65 inch x 0.87 inch)
Weight 125 g ( 0.28 lb)
Ambient conditions
Operating temperature 0 ºC to 40 ºC (32 ºF to 104 ºF)
Humidity (operation) 95 % (not condensing)
Storage temperature -10 ºC to 60 ºC (-14 ºF to 140 ºF)
Humidity (storage) 95 % (not condensing)
Protection class IP-65
Vibration EN61373, inc. IEC 60068-2-6,60068-2-64 6.4 and
60068-2-27
Certificates
Approvals CE, UL, FCC, CTICK, VCCI, IC
