User manual SIPLACE CA-Series 8 Station Extensions
From software version SC.708.0 Edition 12/2014 EN -DRAFT 8.9 Siemens Interface
491
8.8.2 Functions
The PCB is transported into the placement area until the laser light barrier triggers the stop signal
for the PCB conveyor. The lifting table with the PCB stops then moves up into a position in which
the PCB is not yet clamped and can still be moved by the conveyor belts. The two PCB stops are
level with the PCB, and the PCB supports (magnetic pins) are already in contact with the PCB.
The two conveyor belts move the PCB against the PCB stops and align them at the same time.
The lifting table then moves into its top end position, clamps the PCB and releases it from the PCB
stops so as not to affect the placement process. After the placement process, the lifting table and
PCB alignment are lowered and the PCB is moved on.
8
8.9 Siemens Interface
[00116808-xx] SIPLACE Interface HF/X/CA/D3
The conveyor interface on the placement machines from the CA-Series is configured to the
SMEMA
standard. It is, however, still possible to use this interface in accordance with the Siemens stan-
dard. This is a significant benefit when a CA-Series machine is to be integrated into older SI-
PLACE
lines, in which case it would not be necessary to retrofit the older machines to conform to the
SMEMA standard.
Simply configure the conveyor interface of the CA-Series machines to the Siemens standard and
connect the machines using the associated interface cable.
For more information, refer to the "Retrofitting Guide for Siemens Conveyor Interfaces"
[00194343-01].
8 Station Extensions User manual SIPLACE CA-Series
8.10 "Long Board" Option From software version SC.708.0 Edition 12/2014 EN -DRAFT
492
8.10 "Long Board" Option
[00119672-xx] Stopper, long board, SIPLACE HF/X/CA/D3
The following board formats can be placed using the CA-Series machines:
8
8
8
We can supply the Long board option as a retrofit kit for placing PCBs that are over 450 mm long.
If the Long board option is installed, then the following PCB formats can be processed:
8
The retrofit kit consists of the following parts:
– Mechanics, comp.: stopper, sensors, cable and assembly parts
– Optional CD for enabling the function on the SIPLACE Pro computer
– Retrofit instructions
Single conveyor (standard width) 50 mm x 50 mm up to 450 mm x 460
mm
Single conveyor: Wide board 50 mm x 50 mm up to 450 mm x 508
mm
Dual conveyor (standard width) 50 mm x 50 mm up to 450 mm x 216
mm
Dual conveyor: Wide board 50 mm x 50 mm up to 450 mm x 250
mm
Dual conveyor in single conveyor mode 50 mm x 50 mm up to 450 mm x 416
mm
Dual conveyor in "single conveyor", "wide board" mode 50 mm x 50 mm up to 450 mm x 450
mm
Single conveyor "long board" (standard width) 50 mm x 80 mm up to 610 mm x 460
mm
Single conveyor "wide board", "long board" 50 mm x 80 mm up to 610 mm x 508
mm
Dual conveyor "long board" 50 mm x 80 mm up to 610 mm x 216
mm
Dual conveyor "wide board", "long board" 50 mm x 80 mm up to 610 mm x 250
mm
Dual conveyor in "single conveyor", "long board" mode 50 mm x 80 mm up to 610 mm x 416
mm
Dual conveyor in "single conveyor", "wide board", "long
board" mode
50 mm x 80 mm up to 610 mm x 450
mm
User manual SIPLACE CA-Series 8 Station Extensions
From software version SC.708.0 Edition 12/2014 EN -DRAFT 8.10 "Long Board" Option
493
8
For more information, refer to the "Long Board Option" retrofit manual
[00193888-01].
PLEASE NOTE
The Long board option must be ordered 2x for the dual conveyor.
