8 Station Extensions User manua l SIPLACE CA-Series 8.11 Magnetic Pin Support From software version SC.708.0 Edition 12/2014 EN -DR AFT 494 8.1 1 Magnetic Pin Support [001 19680-xx] Magnetic pin sup port HS/HF/X/CA/D-Ser…
User manual SIPLACE CA-Series 8 Station Extensions
From software version SC.708.0 Edition 12/2014 EN -DRAFT 8.10 "Long Board" Option
493
8
For more information, refer to the "Long Board Option" retrofit manual
[00193888-01].
PLEASE NOTE
The Long board option must be ordered 2x for the dual conveyor.
8 Station Extensions User manual SIPLACE CA-Series
8.11 Magnetic Pin Support From software version SC.708.0 Edition 12/2014 EN -DRAFT
494
8.11 Magnetic Pin Support
[00119680-xx] Magnetic pin support HS/HF/X/CA/D-Series
Wide boards tend to deflect during placement such that, under certain circumstances, the compo-
nents can no longer be placed with the desired accuracy. Highly curved PCBs also affect the
placement accuracy. This problem can be easily rectified by fitting magnetic pin supports on the
lifting table.
8
Fig. 8.11 - 1 Magnetic pin support
User manual SIPLACE CA-Series 8 Station Extensions
From software version SC.708.0 Edition 12/2014 EN -DRAFT 8.12 Vision Teach Place
495
8.12 Vision Teach Place
[00119788-xx] Vision teach station
8
Fig. 8.12 - 1 Vision teach station with component camera, type 33
