Samsung Component Placer SM421 Service Manual 4-4 4.1.2. Head Ass’y - B NO. P ART NO. P ART NAME Q ’ TY TYPE REMARK 1 J3212027A MICRO PHOTO SENSOR 3 PM-L24 2 J6025300036 HEX NUT 2 M3 3 J6071 150050 E-RING 2 DIA1.5(SUS) 4…
Head Module
4-3
NO. PART NO. PART NAME Q’TY
TYPE REMARK
41 J7155572A CAMERA CABLE HOLDER 1 J7155572A
42 J7255081A MIRROR MOTOR ISOLATOR 1 J7255081A
43 J7255083A THETA MOTOR ISOLATOR 3 J7255083A
44 J90550209B COMMON NOZZLE HOLDER ASSY 6 J90550209B
44-A J70550431C NOZZLE HOLDER 1 J70550431C
44-B J7055140A STEEL BALL 3 DIA2, SUS304
44-C J7255021B SILICON TUBE(BLACK) 1 SA0705-100B
45 J90551007A SPLINE HOUSING ASS'Y 6 J90551007A
46 J90591004A F-MOVING_12058_LENS_ASSY 1 J90591004A
47 J9060357B HEAD OUTER LED BOARD ASSY 1 Rev 1.1
48-A J9083190A R12_MOTOR_CABLE_ASSY 3 SM21-MD038
48-B J90831009A R34_MOTOR_CABLE_ASSY 3 SM21-MD039
48-C J90831010A R56_MOTOR_CABLE_ASSY 3 SM21-MD040
49-A J90831390A Z1_MOTOR_ASSY SM41-MD026
49-B J90831391A Z2_MOTOR_ASSY SM41-MD027
49-C J90831392A Z3_MOTOR_ASSY SM41-MD028
49-D J90831393A Z4_MOTOR_ASSY SM41-MD029
49-E J90831394A Z5_MOTOR_ASSY SM41-MD030
49-F J90831395A Z6_MOTOR_ASSY SM41-MD031
50 J9083184A R HOME SENSOR CABLE ASSY 1 SM21-HD013
51 J9055357A PULLEY ASSY (Z-AXIS 2) 6 J9055357A
Samsung Component Placer SM421 Service Manual
4-4
4.1.2. Head Ass’y - B
NO. PART NO. PART NAME Q’TY
TYPE REMARK
1 J3212027A MICRO PHOTO SENSOR 3 PM-L24
2 J6025300036 HEX NUT 2 M3
3 J6071150050 E-RING 2 DIA1.5(SUS)
4 J6107044A SPRING 2 AWY 6-50
5 J6601079A BALL BEARING 4 695ZZ
6 J6601080A BALL BEARING 4 MR148ZZ
7 J6601081A CAM FOLLOWER 2 CF3UU-A
8 J6755002A FOLDING MIRROR 1 J6755002A
9 J7055143B CAM 2 J7055143B
10 J7055151A ARM JOINT 1 J7055151A
11 J7055153A MIRROR SCREW 2 J7055153A
12 J7055155A MIRROR JOINT-RIGHT 1 J7055155A
13 J7055204A ARM JOINT 1 J7055204A
14 J7055205A MIRROR JOINT-LEFT 1 J7055205A
15 J7055207B MIRROR SHAFT 1 J7055207B
16 J7055556B MIRROR SENSOR BRACKET 1 J7055556B
17 J7055557A BEARING HOUSING 1 J7055557A
18 J7055557A BEARING HOUSING 1 J7055557A
19 J7055558A MIRROR PIN 1 2 J7055558A
20 J7055559A MIRROR PIN 2 2 J7055559A
21 J7055560A MIRROR SPRING BRACKET 2 J7055560A
Head Module
4-5
NO. PART NO. PART NAME Q’TY
TYPE REMARK
22 J71550570B SIDE ILLUM BODY 1 J71550570B
23 J7155197A MIRROR FIX PLATE 2 J7155197A
24 J7155515A LOWER COVER 2 1 J7155515A
25 J7155522A PULLEY (S-AXIS 1) 1 J7155522A
26 J7155525A MIRROR SENSOR DOG 1 J7155525A
27 J7155526A MIRROR ARM-LEFT 1 J7155526A
28 J7155527A MIRROR ARM-RIGHT 1 J7155527A
29 J7155530A MIRROR SUPPORT 1 J7155530A
30 J7155538A OUTER ILL BRACKET 1 J7155538A
31 J7155539A OUTER ILL SIDE BRACKET 1 J7155539A
32 J7155540A OUTER ILL SIDE BRACKET 1 1 J7155540A
33 J72550084B SIDE REFLECTOR 6 J72550084B
34 J7255085A SIDE ILLUM ISOLATOR 1 J7255085A
35 J7455026A SPRING BUSH 4 J7455026A
36 J90551011A SIDE_ILLUM_GUIDE 2 J90551011A
37 J9060357B HEAD OUTER LED BOARD ASSY 1 Rev 1.1
38 J9060404A HEAD SIDE LED ASSY 1 Rev 1.0
39 J9083179A SIDE ILL U/D SENSOR CABLE ASSY 1 SM21-HD006
39-A J6711132A FITTING 1 M-5HL-M
39-B J6711156A HOSE NIPPLE 1 M-5H-4
