4-C 12ノズルヘッド:NPM 12 NOZZ LE HEAD :NP M パーツレイアウト Ki t N o . キット 品番 Kit N am e キット名称 N6 1006 750 7AA ｾｸｼｮﾝNo. PARTS LAYOUT Section No. - - O23 ( KN610067507AA-20-3 )
Ref
No.
Remarks
R
1
Q'ty
4-B
12ノズルヘッド:NPM
12 NOZZLE HEAD:NPM
ｲﾗｽﾄ
No.
Part No.
品 名品番 数量
R
2
パーツリスト
Kit N
o
.
キット品
番
Kit Name
キット名称
N610067507AA
Part Name
備 考
ｾｸｼｮﾝNo.
PARTS LIST
Section No.
R
3
PLATE
1
1 N210084654AE
MANIFOLD
1
2 N210078980AB
HANDLE
2
3 N210090625AB
BRACKET
1
4 N210084658AB
BRACKET
1
5 N210078994AD
PLATE
2
6 N210084293AB
BRACKET
1
7 N210103911AB
MOTOR
1
9 N510044877AA
S
RMTA-A001A12-MA22
PIN
4
10 N510020607AA MMS5-10
SPACER
2
11 N510008161AA ASF-309E
SPACER
4
12 N510019890AA ASF-350E
JOINT
2
13 KXF0DWCXA00 KQ2H08-02S
JOINT
4
14 KXF02T4AA00 M-5AU-6
BOLT
2
15 N510017516AA
SSS 003 Hexagon socket button head screw M4X10-10.9 A2J (Trivalent)
FAN
1
16 N510044727AA 109P0424H737
O22
--
( KN610067507AA-20-2 )
4-C
12ノズルヘッド:NPM
12 NOZZLE HEAD:NPM
パーツレイアウト
Ki
t
N
o
.
キット
品番
Kit Name
キット名称
N610067507AA
ｾｸｼｮﾝNo.
PARTS LAYOUT
Section No.
--
O23
( KN610067507AA-20-3 )
Ref
No.
Remarks
R
1
Q'ty
4-C
12ノズルヘッド:NPM
12 NOZZLE HEAD:NPM
ｲﾗｽﾄ
No.
Part No.
品 名品番 数量
R
2
パーツリスト
Kit N
o
.
キット品
番
Kit Name
キット名称
N610067507AA
Part Name
備 考
ｾｸｼｮﾝNo.
PARTS LIST
Section No.
R
3
COLLAR
12
1 N210013388AA
SPRING
24
2 N210016901AB
GUIDE
12
3 N210016902AB
COLLAR
12
4 N210013386AB
NUT
12
5 N210009483AB
COLLAR
12
6 N210013382AB
HOUSING
12
7 N210090621AD
HOLDER
12
8 N210007281AD
PIECE
24
9 N210110221AA
SPRING
12
10 N210068065AA
A
SPRING
12
11 N210014666AC
A
CLAMP-ARM
24
12 N210098763AB
A
NOZZLE HOLDER
12
13 N610067607AD
FILTER
12
14 N610097899AA
BALL-SPLINE
12
15 N510051262AA 2LT4XQZCSS+145.5LP-(C)(12341332X000)
BEARING
12
16 N510011405AA DDRF-830ZZ R P0P25LY72
WASHER
24
17 N510026562AA MMSRB6-0.5
PULLEY
12
18 N510019396AA P14-2GT-6-33(K0508-005-02)
BEARING
36
19 N510003588AA DDL-1060ZZ H P0P25LY121
JOINT
12
20 KXF02T3AA00 M-5AU-4
BEARING
12
21 N510003597AA DDLF-630ZZ H P0P25LY72
PACKING
24
22 N555MYA3 MYA-3
SHIM
12
23 N510028628AA RF002004020
BEARING
12
24 N510019154AA DDR-620ZZY52 H P0P13LY72
PIN
12
25 N510049558AA N2X5-07
BEARING
12
26 N510011382AA DDLF-850ZZ H P0P25LY121
SCREW
24
27 XXE25C3FT
Hexagon socket set screw Flat point M2.5X3-45H SOB
O24
--
( KN610067507AA-20-3 )
