10-A Y軸:NP M- D Y-Axis:NP M-D パーツレイアウト Ki t N o . キット 品番 Kit N am e キット名称 N6 1010 960 5AA ｾｸｼｮﾝNo. PARTS LAYOUT Section No. - - S37 ( KN610109605AA-08-1 )
Ref
No.
Remarks
R
1
Q'ty
9-D
X軸:NPM-D
X-Axis:NPM-D
ｲﾗｽﾄ
No.
Part No.
品 名品番 数量
R
2
パーツリスト
Kit N
o
.
キット品
番
Kit Name
キット名称
N610109604AA
Part Name
備 考
ｾｸｼｮﾝNo.
PARTS LIST
Section No.
R
3
XY-Axis Front Side Wiring:NPM-
D
1
1 N610112730AA
XY-Axis Rear Side Wiring:NPM-
D
1
2 N610112731AA
S36
--
( KN610109604AA-08-4 )
10-A
Y軸:NPM-D
Y-Axis:NPM-D
パーツレイアウト
Ki
t
N
o
.
キット
品番
Kit Name
キット名称
N610109605AA
ｾｸｼｮﾝNo.
PARTS LAYOUT
Section No.
--
S37
( KN610109605AA-08-1 )
Ref
No.
Remarks
R
1
Q'ty
10-A
Y軸:NPM-D
Y-Axis:NPM-D
ｲﾗｽﾄ
No.
Part No.
品 名品番 数量
R
2
パーツリスト
Kit N
o
.
キット品
番
Kit Name
キット名称
N610109605AA
Part Name
備 考
ｾｸｼｮﾝNo.
PARTS LIST
Section No.
R
3
PLATE
2
1 N210130128AC
STOPPER
4
2 N210077946AA
POST
6
3 N210097302AA
POST
4
4 N210141785AA
COVER
6
5 N210133007AA
PIECE
8
6 N210109439AA
SHEET
2
7 N210137246AA
BRACKET
2
8 N210130130AB
BRACKET
2
9 N210105536AA
BRACKET
4
10 N210136907AA
PLATE
2
11 N210136906AA
PLATE
2
12 N210136905AB
Y-BEAM
1
13 N610110930AB
LINEAR-WAY
1
14 N510055993AA SHS30LV4QZUUC1S+2280LH(00042206C000)
LINEAR-SCALE
1
15 N510054905AA ST773A-1900PF
MOTOR
10
16 N510055030AA
S
DS045M448B01
SCREW
24
17 N510018282AA
Cross recessed Truss head machine screw M4X8-4.8 A2J (Trivalent)
WASHER
4
18 N510027223AA
Round finish plain washer (JIS B 1256:1978) 12 10H A2J (Trivalent)
SCREW
4
19 N510056624AA
Hexagon socket set screw Flat point M12X60-45H A2J (Trivalent)
JOINT
4
20 N431KQ2L04M6 KQ2L04-M6
SCREW
8
21 XXE6D6FT
Hexagon socket set screw Cup point M6X6-45H SOB
BOLT
8
22 N510045098AA
Hexagon socket head cap screw M8X25-10.9 A2J (Trivalent) (MEC process
SPRING-PIN
4
23 N510029211AA 1017003-60016
BOLT
10
24 N510017189AA
Hexagon socket head cap screw M12X30-10.9 A2J (Trivalent)
BOLT
7
25 N510017190AA
Hexagon socket head cap screw M12X35-10.9 A2J (Trivalent)
PIN
3
26 N510006098AA 1017003-40010
BOLT
4
27 N510017627AA
Hexagon socket Flat head bolt M4X6-10.9 A2J (Trivalent)
BOLT
8
28 N510000315AA
SSS 003 Hexagon socket button head screw M3X4-12.9 SOB
S38
--
( KN610109605AA-08-1 )
