N7202A008B23 - 第78页
17-B 全 体 カバー: NPM- D W h ole Cover:NP M- D パーツレイアウト Ki t N o . キット 品番 Kit N am e キット名称 N6 1011 162 1AA ｾｸｼｮﾝNo. PARTS LAYOUT Section No. - - S57 ( KN610111621AA-06-2 )
Ref
No.
Remarks
R
1
Q'ty
17-A
全
体
カバー:NPM-D
Whole Cover:NPM-D
ｲﾗｽﾄ
No.
Part No.
品 名品番 数量
R
2
パーツリスト
Kit N
o
.
キット品
番
Kit Name
キット名称
N610111621AA
Part Name
備 考
ｾｸｼｮﾝNo.
PARTS LIST
Section No.
R
3
COLLAR
4
1 N210118825AA
WASHER
3
2 N210130223AA
BRACKET
1
3 N210105534AB
BRACKET
2
4 N210144578AA
BRACKET
1
5 N210145927AA
BRACKET
2
6 N210105542AD
NUT-PLATE
2
7 N210056490AA
BRACKET
4
8 N210134495AA
COVER
2
9 N210138677AC
BRACKET
2
10 N210138678AB
BRACKET
2
11 N210138679AA
COVER
1
12 N610113428AA
COVER
1
13 N610113799AA
COVER
1
14 N610113800AA
COVER
1
15 N610113430AA
COVER
1
16 N610122153AA
COVER
1
17 N610113486AA
COVER
1
18 N610113434AA
COVER
2
19 N610116840AA
COVER
1
20 N610091205AB
COVER
1
21 N610091206AB
COVER
1
22 N610116307AA
COVER
1
23 N610116308AA
COVER
1
24 N610116309AA
COVER
1
25 N610116837AA
COVER
1
26 N610116838AA
CAP
49
27 N510024547AA CP-328-B-5-G
BOLT
49
28 N510017629AA
Hexagon socket Flat head bolt M5X10-10.9 A2J (Trivalent)
SCREW
12
29 N510018257AA
Cross recessed Truss head machine screw M4X10-4.8 A2J (Trivalent)
SWITCH
2
30 N510015338AA
S
D4NS-1BF
SCREW
12
31 N510018158AA
Cross recessed Countersunk head machine screw M3X6-4.8 A2J (Trivalent)
PLATE
4
32 N510043073AA YN-001U
CUSHION
1
33 N510048932AA C-300-B-5X10-Si WF
JOINT
2
34 KXF06F4AA00 53015030-WM
SCREW
8
35 N510018278AA
Cross recessed Truss head machine screw M4X5-4.8 A2S (Trivalent)
CABLE-SUPPORT
12
36 N510048517AA FT4
SCREW
4
37 N510018155AA
Cross recessed Countersunk head machine screw M3X4-4.8 A2J (Trivalent)
S56
--
( KN610111621AA-06-1 )
17-B
全
体
カバー:NPM-D
Whole Cover:NPM-D
パーツレイアウト
Ki
t
N
o
.
キット
品番
Kit Name
キット名称
N610111621AA
ｾｸｼｮﾝNo.
PARTS LAYOUT
Section No.
--
S57
( KN610111621AA-06-2 )
Ref
No.
Remarks
R
1
Q'ty
17-B
全
体
カバー:NPM-D
Whole Cover:NPM-D
ｲﾗｽﾄ
No.
Part No.
品 名品番 数量
R
2
パーツリスト
Kit N
o
.
キット品
番
Kit Name
キット名称
N610111621AA
Part Name
備 考
ｾｸｼｮﾝNo.
PARTS LIST
Section No.
R
3
COVER
2
1 N210098456AB
FRAME
1
2 N210092102AM
FRAME
1
3 N210092103AM
PLATE
4
4 N210096995AC
PLATE
4
5 N210096996AC
PLATE
4
6 N210096997AC
SEAL
4
7 N210115505AA
SEAL
4
8 N210115507AA
SEAL
4
9 N210115508AA
WASHER
14
10 N210117336AA
WASHER
22
11 N210117342AA
STOPPER
2
12 N210105535AC
STOPPER
1
13 N210139638AA
STOPPER
1
14 N210139639AA
BRACKET
2
15 N210134125AA
BRACKET
4
16 N210092152AB
LEVER
1
17 N210092154AD
LEVER
1
18 N210092156AD
NUT-PLATE
2
19 N210092157AB
BRACKET
2
20 N210098453AB
COVER
2
21 N210105548AA
BRACKET
2
22 N210105550AA
COVER
2
23 N210124008AB
COVER
2
24 N210124009AA
COVER
1
25 N610091209AA
COVER
1
26 N610091210AA
COVER
1
27 N610091211AA
COVER
1
28 N610091212AA
RUBBER-LEG
2
29 N510006026AA C-30-RK-16-UL
SWITCH
2
30 N510034226AA
S
D4NH-9BBC
GAS-SPRING
4
31 N510046058AA
S
KMF100-20M
BOLT
8
32 N510020762AA MMSB10-10
WASHER
20
33 N510038123AA CC-0410-20
SPACER
2
34 N510030914AA CB-307E
WASHER
2
35 N510018472AA
Iron round plain washer3X10X1.0(chromeite) A2J (Trivalent)
E-RING
4
36 KXF0AG0AA00 B-1024-4
MAGNET
4
37 N510042575AA MC-158
SPACER
2
38 N510030906AA CB-350E
BOLT
2
39 N510017335AA
Hexagon socket head cap screw M3X55-10.9 A2J (Trivalent)
SCREW
42
40 N510048366AA
Cross recessed Truss head machine screw M4X12-4.8 A2J (Trivalent)
SCREW
24
41 N510048368AA
Cross recessed Truss head machine screw M4X15-4.8 A2J (Trivalent)
GASKET
4
42 KXF0E1TSA00 C-300-EG-5-10
CABLE-SUPPORT
2
43 N510048516AA FT3
HINGE
4
44 N610074492AA
WASHER
8
45 N510048767AA PSW-0409-08
BUSH
8
46 N510056255AA PE4050-9130
S58
--
( KN610111621AA-06-2 )
