Machine frame SIPLACE 80 F4
Page 31 / 33 19.11.2021
Pos. Item no. Description Part marking
155 00343700-01 COVER FOR 80F3 / F4 12K / F4 6K Spare Part
156 00845024-01 HEXAGON SOCKET HEAD CAP
SCREW M4 X 8-8.8
157 00343361-01 DUST PLATE OPEND
158 00845025-01 HEXAGON SOCKET HEAD CAP
SCREW M4 X 10-8.8
159 00343722-01 TENSION PLATE RIGHT SIDE
160 00343721-01 TENSION PLATE LEFT SIDE
161 00343363-01 INSERTING SHEET STEEL 2
162 00343362-01 INSERTING SHEET STEEL 1
163 00048335-01 DIN 9021 - 4.3 - 140 HV - ST DISK
164 00320817-02 HINGED PLATE SPARE PART
165 00303614-03 HOOD SWITCH INPUT Spare Part
166 00304351S01 SAFETY SWITCH AZ15/16 1S+1OE
00305815-03 CABLE: COVER SWITCH INPUT
167 00303617-03 HOOD SWITCH OUTPUT Spare Part
168 00304351S01 SAFETY SWITCH AZ15/16 1S+1OE
00305818-03 CABLE: COVER SWITCH OUTPUT
171 00349922-01 PC-HOLDER 4
172 00347747-01 CURVED CROSSHEAD PC-SUPP.3
(S23)
173 00337391-01 PLUG-SQUARE GPN270R10050
100*50
SPARE PART
174 00349923-02 MOUNTING PC-SUPPORT 4
175 00349924-01 HOUSING PC-SUPPORT 4
176 00328376-01 GUIDE PC-SUPPORT 2 SPARE PART
177 00845060-01 HEXAGON SOCKET HEAD CAP
SCREW M6 X 25-8.8
178 00095474-01 DISC 6,4 DIN125-A Spare
179 00845024-01 HEXAGON SOCKET HEAD CAP
SCREW M4 X 8-8.8
180 00095472-01 PLAIN WASHER A 4.3-140HV-ST
181 00349929-01 MAIN ERROR DISPLAY PC-SUPPORT
4
182 00321320S01 INCANDESCENT LAMP 24V/5W BASE
BA15D
WEAR PART
183 00349930-01 LAMP HOLDER PC-SUPPORT 4
184 00326152-01 PULL RELIEF TYPEKK2
Machine frame SIPLACE 80 F4
Page 32 / 33 19.11.2021
Pos. Item no. Description Part marking
185 00313846-01 DIN912-M5 X 18-A2-70
186 00321575-02 CABLE: MAIN ERROR DISPLAY
187 00349928-01 CABLE COVER PC-SUPPORT 4
188 00845023-01 HEXAGON SOCKET HEAD CAP
SCREW M4 X 6-8.8
189 03052954-01 MONITOR HOLDER S U. F
COMPLETE
SPARE PART
190 00350470-01 REST SCENIC 620 - PC-SUPPORT 4
191 00845059-01 HEXAGON SOCKET HEAD CAP
SCREW M6 X 20-8.8
192 00095474-01 DISC 6,4 DIN125-A Spare
193 00347748-01 ANGLE LEFT SIDE (PC-SUPP.3, S23)
194 00346042-01 PLATE PC-SUPPORT 3
195 00332287-01 HEXAGON SOCKET HEAD CAP
SCREW
196 00048336-01 WASHER
197 00332543-01 ELASTIC THRUST PIECE LATERAL
D=12
SPARE PART
198 00347749-01 ANGLE RIGHT SIDE (PC-SUPP.3,
S23)
205 00321439-03 CONTROL UNIT - CONVERSION
BOARD PORTAL
206 00321536-02 CABLE: TRACK (Y-AXIS)
207 00321537-01 CABLE: MOTOR/TACHO X-AXIS
208 00321538-02 CABLE: TRACK (X-AXIS)
209 00321539-01 CABLE: MOTOR DR-AXIS
SP/IC1-HEAD
210 00321540-02 CABLE: TRACK SIGNALS DR-AXIS
SP/IC1-HEAD
211 00321541-03 CABLE: MOTOR/TACHO Z-AXIS
SP/IC1-HEAD
212 00321542-02 CABLE: TRACK SIGNALS Z-AXIS
SP/IC1-HEAD
213 00321544-03 CABLE: MOTOR/TACHO DP1-AXIS
W1/W2
214 00321546-03 CABLE: TRACK SIGNALS DP1-AXIS
215 00321547-03 CABLE: CRASH-BEROS
216 00321548-02 CABLE: CONTROL UNIT-
CONVERSION BOARD
Spare Part
Machine frame SIPLACE 80 F4
Page 33 / 33 19.11.2021
Pos. Item no. Description Part marking
217 00321585-04 CABLE CAN-BUS GANTRY 1
218 00321587-03 CABLE: CRASH-SIGNAL (TERMINAL
BD CONV.)
219 00321787-02 CABLE: VOLTAGE STAR-MOTOR
PORTAL 1
220 00321789-02 CABLE: VOLTAGE ILLUMINATION
PORTAL 1
221 00321898-03 CABLE: CONTROL UNIT -
CONVERSION BOARD P
222 00321899-01 CABLE: TRACK SIGNALS Z-AXIS IC2
223 00322256-01 CABLE FOR PORTAL SPARE PART
224 00322257-01 CABLE FOR PORTAL HEAD AXIS SPARE PART
225 00322258-01 CABLE FOR PORTAL CAN BUS SPARE PART
226 00322259-01 CABLE FOR PORTAL DP1-AXIS SPARE PART
227 00322261-01 CABLE FOR PORTAL STAR/Z-AXIS SPARE PART
228 00322262-01 CABLE FOR PORTAL X-MOTOR SPARE PART
229 00322264-01 CABLE FOR PORTAL X-MOTOR/Y-
TRACK
SPARE PART
230 00322265-02 GANTRY CABLE IC2-HEAD SPARE PART
231 00321900-02 CABLE: TRACK SIGNALS DR-AXIS
IC2
