WPC6
Page 28 / 34 15.11.2021
Pos. Item no. Description Part marking
WH 26X26MM
77 03056989-01 SAFETY SENSOR LOADING FLAP SPARE PART
03053775-01 BNS 260 SENSOR SPARE PART
03083109-01 CABLE: LOADING FLAP CLOSE
MAGNET
00304916S01 AMPMODU PLUG 2*3 POL. STANDARD PARTS
00304845S01 AMPMODU SOCKET CONTACT
0.12-0.60MM²
Spare Part
03002215-01 MINI MATE-N-LOK CONNECTOR,
FEMALE, 2-POL
84 03086203-01 SENSOR MOUNT
03052805-01 FITTED BOLT M6X26.7
03053777-01 SPACER BNS 260
176 00098615-01 DEEP-GROOVE BALL BEARING
5*16*5 625-2Z
Spare Part
03044699-01 DIN 625 - 638/8 - 2Z
00316894-01 WASHER
00095482-01 DIN 471-6X0.7-C67 Spare Part
03087046-01 ISO 4762 - M 3 X 12-8.8, TUFLOK
03042540-01 ISO 4762 - M 3 X 5-A2-70
03042541-01 ISO 4762 - M 3 X 6-A2-70
03042542-01 ISO 4762 - M 3 X 8-A2-70 STANDARD PARTS
03042553-01 ISO 4762 - M 4 X 12-A2-70 Spare Part
00337990-01 DIN912-M4 X 16-A2-70
03042545-01 ISO 4762 - M 3 X 16-A2-70
03042551-01 ISO 4762 - M 4 X 8-A2-70
03043120-01 ISO 4762 - M 5 X 14-A2-70
03043121-01 ISO 4762 - M 5 X 18-A2-70
03042573-01 ISO 4762 - M 6 X 16-A2-70
03046987-01 DIN 916 - M2,5 X 6-A2-70
00309319-01 ADJUSTING SHIM
00311089-01 DIN 988-5X10X1-ST 2 K 50
00305131-01 DIN 988-6X12X1-ST 2 K 50 STANDARD PARTS
00322618-01 ADJUSTING SHIM 8*14*1
00311958-01 ADJUSTING SHIM 8*14*1.5
03040011-01 DIN 923 M5 X 3-A2-50
WPC6
Page 29 / 34 15.11.2021
Pos. Item no. Description Part marking
03047303-01 DIN 7991-M3 X 8-A2-70
03004774-01 FLAP STOPPER BELOW CPL. / NSM
03057513-01 FLAP STOPPER BELOW / NSM
03004608-01 SYLOMER R12,5 (BLUE) 12X10X24
00313201-01 SLOTTED CHEESE HEAD SCREW
M4*10
03004642-01 FLAP STOPPER ABOVE CPL. / NSM SPARE PART
03004682-01 FLAP STOPPER ABOVE / NSM
03004608-01 SYLOMER R12,5 (BLUE) 12X10X24
00313201-01 SLOTTED CHEESE HEAD SCREW
M4*10
03058047-01 PLUGHOLDER WPC 5
03042550-01 ISO 4762 - M 4 X 6-A2-70
03083948-01 COVER TRAY / NSM
03072433-01 SPACER D6 D3,2 L22
00319192-01 CABLE CLIP D=5MM H2P
POLYAMIDE
STANDARD PARTS
03052392-01 SN 62355 - M4X8-10.9, VERZ. DSP
78 03053776-01 ACTUATOR BPS 260-2 SPARE PART
03050751-01 MOUNTING SOCKET TYPE TM1S4
00328008-01 DIN 7984-M3 X 5-A2
03072074-01 CABLE TIE MOUNTS TY8F1
03042548-01 ISO 4762 - M 3 X 25-A2-70 STANDARD PARTS
00805102-01 FIXING PEDESTAL F.CABLE TIE
TY3-G1S ADHE
03082216-01 SN 62355 - M4X10-A2-70
00320872-01 CABLE CLIP D=6.5MM H3P,
POLYAMIDE
STANDARD PARTS
03080635-01 BERO 3RG4 / M12 / SN=2,0MM / 1S
03057027-01 BERO 3RG4 / M8 / SN=1,5MM / 1S
03053775-01 BNS 260 SENSOR SPARE PART
03002215-01 MINI MATE-N-LOK CONNECTOR,
FEMALE, 2-POL
82 03070248-01 BERO 3RG4613 AB01 M18X1 SN
12MM
00304916S01 AMPMODU PLUG 2*3 POL. STANDARD PARTS
00304845S01 AMPMODU SOCKET CONTACT
0.12-0.60MM²
Spare Part
WPC6
Page 30 / 34 15.11.2021
Pos. Item no. Description Part marking
00304916S01 AMPMODU PLUG 2*3 POL. STANDARD PARTS
00304845S01 AMPMODU SOCKET CONTACT
0.12-0.60MM²
Spare Part
03006443-01 MINI MATE-N-LOK CONNECTOR,
FEMALE, 4-POL
03006443-01 MINI MATE-N-LOK CONNECTOR,
FEMALE, 4-POL
03006443-01 MINI MATE-N-LOK CONNECTOR,
FEMALE, 4-POL
00304916S01 AMPMODU PLUG 2*3 POL. STANDARD PARTS
00304845S01 AMPMODU SOCKET CONTACT
0.12-0.60MM²
Spare Part
03002215-01 MINI MATE-N-LOK CONNECTOR,
FEMALE, 2-POL
00304916S01 AMPMODU PLUG 2*3 POL. STANDARD PARTS
00304845S01 AMPMODU SOCKET CONTACT
0.12-0.60MM²
Spare Part
03002215-01 MINI MATE-N-LOK CONNECTOR,
FEMALE, 2-POL
00304916S01 AMPMODU PLUG 2*3 POL. STANDARD PARTS
00304845S01 AMPMODU SOCKET CONTACT
0.12-0.60MM²
Spare Part
00304916S01 AMPMODU PLUG 2*3 POL. STANDARD PARTS
00304845S01 AMPMODU SOCKET CONTACT
0.12-0.60MM²
Spare Part
00360168-01 MINI MATE-N-LOK SOCKET 3-POLE
00304916S01 AMPMODU PLUG 2*3 POL. STANDARD PARTS
00304845S01 AMPMODU SOCKET CONTACT
0.12-0.60MM²
Spare Part
00360168-01 MINI MATE-N-LOK SOCKET 3-POLE
00304916S01 AMPMODU PLUG 2*3 POL. STANDARD PARTS
00304845S01 AMPMODU SOCKET CONTACT
0.12-0.60MM²
Spare Part
00360168-01 MINI MATE-N-LOK SOCKET 3-POLE
00304916S01 AMPMODU PLUG 2*3 POL. STANDARD PARTS
00304845S01 AMPMODU SOCKET CONTACT
0.12-0.60MM²
Spare Part
03047529-01 TRANSMITTED LIGHT BARRIER
SUNX EX-13EA-P
03057837-01 BERO REFERENCE-POINT FEED AXIS SPARE PART
