Student Guide HS-50 Advanced I 06/2002 Edition
12 Preventive Maintenance
7
RISK OF COMBUSTION 0
12
WARNING 0
12
12.1.1 Description of symbols
12
12
Tools and consumables required
12
Please note
12
Tip
12
Caution
: Never carry out cleaning work using alcohol near a naked light or flame.
: Never spray lubricant or cleaning agent from aerosol cans near a naked light or flame.
: DO NOT SMOKE.
: Always wear safety goggles and gloves when cleaning modules with concentrated
ethyl alcohol.
: If you accidentally spray ethyl alcohol in your eyes, wash your eyes immediately with
lots of water.
06/2002 Edition Student Guide HS-50 Advanced I
12 Preventive Maintenance
8
12.2 Everything you will need for maintenance
The following lists of materials contain all the tools, equipment and consumables you will need to
maintain your automatic placement system.
Never use solvents for cleaning - only use ethyl alcohol.
Apply all lubricants sparingly and at the specified points.
12.2.1 Tools and equipment
Have the following tools and equipment ready before starting maintenance:
Tools and equipment From item number
Waste bin
Vacuum cleaner
Drip tray
Brush
Brush with short bristles
Scissors
Set of Allen keys
Set of slotted-head screwdrivers
Pliers (in service box) 00346929-01
Laboratory gloves
Metal drill bit, 1.1 mm diameter 00092022-01
Metal drill bit, 1.4 mm diameter 00092026-01
Oilstone/whetstone
Grease gun 00366174-01
Student Guide HS-50 Advanced I 06/2002 Edition
12 Preventive Maintenance
9
12.2.2 Consumables
Have the following consumables ready before starting maintenance:
12.2.3 Spare parts
Have the following spare parts ready before starting maintenance:
Consumables From item number
Cloth, lint-free
Cottonwool buds, lint-free
00352931-01
SIPLACE cleaning cloth 00315253-01
Lens cleaning cloth (e.g. Kodak)
Ethyl alcohol
ISOFLEX TOPAS, NCA 52 00328369-01can 1kg
00330850-01 tube 50 g
UNISILKON L250L 00310259-01
WD40, 400 ml 00325833-01
Syringe with Klüber Structovis GHD 00367071-01
Spare parts From item number
Filter cartridge 00336902-01
Silencer for the Collect&Place head 00320964-01
O-ring for valve plunger 00345127-01
Magazine with cleaned ceramic nozzles or new nozzles
Set of cleaned / new sleeves
Set of cleaned / new valve plungers
Valve plunger 00330711-02 (12 pieces)
Toothed belt of Z axis 00334936-01
Distributor block 00319827-02
O-ring of turning station 00320043-01
