\ ## File converted by makonv at Wed Nov 21 13:37:20 2001 \
{
This file is the camera bloc of the REAL.MA untill SW-version 501
\ Kamera-Individuumdaten \
Only the calibration values are in here. The standard settings of the
cameras in the DataBase system
\ Datei \ "KAMDAT.MA"|
this file is changed with calibration of the machine in SITEST
\ Version \ "31.503.011119_E"|
\ Maschinentyp \ "HS50"|
\ Kamerabeschreibung 1. Kamera \
(counted like gantry arrangement on S-machines. Left gantry of the working
area first)
\ Sensorsystem_Individuum_Nr \ 4005,
Standard-PCB-camera gantry
4
\ Auswerte_Nr \ 1,
connection to Vision controller (MVS-System) for working area 1
\ Kanal-Nummer \ 2,
Input coding >channel< at Visionsystem
\ *** Nachschwingzeit *** \ 50,
waiting time (in msec. until oscillating of the gantry stopped) before start to
read out the CCD Sensor of PCB-camera
\ ** Korrekturfaktor_A_X ** \ -14,
to calculate the pixel size by matirix math. calibrated with SITEST
\ ** Korrekturfaktor_B_X ** \ 11596,
to calculate the pixel size by matirix math. calibrated with SITEST
\ ** Korrekturfaktor_C_X ** \ 0,
by standard 0
\ ** Korrekturfaktor_A_Y ** \ -13,
to calculate the pixel size by matirix math. calibrated with SITEST
\ ** Korrekturfaktor_B_Y ** \ -11598,
to calculate the pixel size by matirix math. calibrated with SITEST
\ ** Korrekturfaktor_C_Y ** \ 0,
by standard 0
\ ** Kamera_Offset_X ** \ 352,
PCB-camera -comp.-camera-offset calibrated with Segment 1 at Segment
Offset bottom
\ ** Kamera_Offset_Y ** \ -100837,
PCB-camera -comp.-camera-offset calibrated with Segment 1 at Segment
Offset bottom
\ ** Kamera_Offset_Z ** \ 0,
The camera do not have an Angle Offset, here always 0. (each camera
have an mounting angle)
\ ** Kamera_Offset_Winkel ** \ 7,
PCB camera mounting angle on the gantry. calibrated with SITEST
\ XU_Pixel \ 11596,
Pixel size in X direction in nm. calibrated with SITEST
\ YU_Pixel \ 11598]
Pixel size in Y direction in nm. calibrated with SITEST
\ Kamerabeschreibung 2. Kamera \
(counted like gantry arrangement on S-machines. Right gantry of the
working area second)
\ Sensorsystem_Individuum_Nr \ 1005,
Standard-PCB-camera gantry 1
\ Auswerte_Nr \ 1,
connection to Vision controller (MVS-System) for working area 1
\ Kanal-Nummer \ 1,
Input coding >channel< at Visionsystem
\ *** Nachschwingzeit *** \ 50,
waiting time (in msec. until oscillating of the gantry stopped) before start to
read out the CCD Sensor of PCB-camera
\ ** Korrekturfaktor_A_X ** \ 61,
to calculate the pixel size by matirix math. calibrated with SITEST
\ ** Korrekturfaktor_B_X ** \ 11595,
to calculate the pixel size by matirix math. calibrated with SITEST
\ ** Korrekturfaktor_C_X ** \ 0,
by standard 0
\ ** Korrekturfaktor_A_Y ** \ 68,
to calculate the pixel size by matirix math. calibrated with SITEST
\ ** Korrekturfaktor_B_Y ** \ -11587,
to calculate the pixel size by matirix math. calibrated with SITEST
\ ** Korrekturfaktor_C_Y ** \ 0,
by standard 0
\ ** Kamera_Offset_X ** \ 619,
PCB-camera -comp.-camera-offset calibrated with Segment 1 at Segment
Offset bottom
\ ** Kamera_Offset_Y ** \ -100794,
PCB-camera -comp.-camera-offset calibrated with Segment 1 at Segment
Offset bottom
\ ** Kamera_Offset_Z ** \ 0,
The camera do not have an Angle Offset, here always 0.(each camera
have an mounting angle)
\ ** Kamera_Offset_Winkel ** \ -32,
PCB camera mounting angle on the gantry. calibrated with SITEST
\ XU_Pixel \ 11595,
Pixel size in X direction in nm. calibrated with SITEST
\ YU_Pixel \ 11588]
Pixel size in Y direction in nm. calibrated with SITEST
\ Kamerabeschreibung 3. Kamera \
\ Sensorsystem_Individuum_Nr \ 4012,
Standard-comp.-camera gantry
4
\ Auswerte_Nr \ 1,
connection to Vision controller (MVS-System) for working area 1
\ Kanal-Nummer \ 4,
Input coding >channel< at Visionsystem. Same connector than ch.2
\ *** Nachschwingzeit *** \ 0,
waiting time only valid for PCB-camera
\ ** Korrekturfaktor_A_X ** \ -108,
to calculate the pixel size by matirix math. calibrated with SITEST
\ ** Korrekturfaktor_B_X ** \ -49495,
to calculate the pixel size by matirix math. calibrated with SITEST
\ ** Korrekturfaktor_C_X ** \ 0,
by standard 0
\ ** Korrekturfaktor_A_Y ** \ 92,
to calculate the pixel size by matirix math. calibrated with SITEST
\ ** Korrekturfaktor_B_Y ** \ -49434,
to calculate the pixel size by matirix math. calibrated with SITEST
\ ** Korrekturfaktor_C_Y ** \ 0,
by standard 0
\ ** Kamera_Offset_X ** \ 0,
PCB-camera -comp.-camera-offset reference is comp.camera so here is
always 0
\ ** Kamera_Offset_Y ** \ 0,
PCB-camera -comp.-camera-offset reference is comp.camera so here is
always 0
Edition 1.0 1 KAMDAT_MA_e.xls KAMDAT.MA SD EA1 S GC Training
\ ** Kamera_Offset_Z ** \ 0,
The camera do not have an Angle Offset, here always 0.(each camera
have an mounting angle)
\ ** Kamera_Offset_Winkel ** \ -3,
comp. camera mounting angle to the turning level of the placement STAR.
calibrated with SITEST
\ XU_Pixel \ 49494,
Pixel size in X direction in nm. calibrated with SITEST
\ YU_Pixel \ 49434]
Pixel size in Y direction in nm. calibrated with SITEST
\ Kamerabeschreibung 4. Kamera \
\ Sensorsystem_Individuum_Nr \ 1012,
Standard-comp.-camera gantry 1
\ Auswerte_Nr \ 1,
connection to Vision controller (MVS-System) for working area 1
\ Kanal-Nummer \ 3,
Input coding >channel< at Visionsystem. Same connector than ch.1
\ *** Nachschwingzeit *** \ 0,
waiting time only valid for PCB-camera
\ ** Korrekturfaktor_A_X ** \ -3,
to calculate the pixel size by matirix math. calibrated with SITEST
\ ** Korrekturfaktor_B_X ** \ -49366,
to calculate the pixel size by matirix math. calibrated with SITEST
\ ** Korrekturfaktor_C_X ** \ 0,
by standard 0
\ ** Korrekturfaktor_A_Y ** \ -13,
to calculate the pixel size by matirix math. calibrated with SITEST
\ ** Korrekturfaktor_B_Y ** \ -49294,
to calculate the pixel size by matirix math. calibrated with SITEST
\ ** Korrekturfaktor_C_Y ** \ 0,
by standard 0
\ ** Kamera_Offset_X ** \ 0,
PCB-camera -comp.-camera-offset reference is comp.camera so here is
always 0
\ ** Kamera_Offset_Y ** \ 0,
PCB-camera -comp.-camera-offset reference is comp.camera so here is
always 0
\ ** Kamera_Offset_Z ** \ 0,
The camera do not have an Angle Offset, here always 0.(each camera
have an mounting angle)
\ ** Kamera_Offset_Winkel ** \ 2,
comp. camera mounting angle to the turning level of the placement STAR.
calibrated with SITEST
\ XU_Pixel \ 49366,
Pixel size in X direction in nm. calibrated with SITEST
\ YU_Pixel \ 49294]
Pixel size in Y direction in nm. calibrated with SITEST
\ Kamerabeschreibung 5. Kamera \
(first the left gantry of the working area)
\ Sensorsystem_Individuum_Nr \ 3005,
3. mean gantry 3 5 is Type nr. of the Standard-PCB-camera
\ Auswerte_Nr \ 2,
Vision system for the 2nd working area
\ Kanal-Nummer \ 2,
all cameras of 3rd gantry on connector >channel< 2/4
\ *** Nachschwingzeit *** \ 50,
waiting time (in msec. until oscillating of the gantry stopped) before start to
read out the CCD Sensor of PCB-camera
\ ** Korrekturfaktor_A_X ** \ 108,
to calculate the pixel size by matirix math. calibrated with SITEST
\ ** Korrekturfaktor_B_X ** \ -11540,
to calculate the pixel size by matirix math. calibrated with SITEST
\ ** Korrekturfaktor_C_X ** \ 0,
by standard 0
\ ** Korrekturfaktor_A_Y ** \ 107,
to calculate the pixel size by matirix math. calibrated with SITEST
\ ** Korrekturfaktor_B_Y ** \ 11552,
to calculate the pixel size by matirix math. calibrated with SITEST
\ ** Korrekturfaktor_C_Y ** \ 0,
by standard 0
\ ** Kamera_Offset_X ** \ -36,
PCB-camera -comp.-camera-offset calibrated with Segment 1 at Segment
Offset bottom
\ ** Kamera_Offset_Y ** \ 101032,
PCB-camera -comp.-camera-offset calibrated with Segment 1 at Segment
Offset bottom
\ ** Kamera_Offset_Z ** \ 0,
The camera do not have an Angle Offset, here always 0.(each camera
have an mounting angle)
\ ** Kamera_Offset_Winkel ** \ 53,
PCB camera mounting angle on the gantry. calibrated with SITEST
\ XU_Pixel \ 11541,
Pixel size in X direction in nm. calibrated with SITEST
\ YU_Pixel \ 11553]
Pixel size in Y direction in nm. calibrated with SITEST
\ Kamerabeschreibung 6. Kamera \
\ Sensorsystem_Individuum_Nr \ 2005,
2 mean gantry 2 5 is Type nr. of the Standard-PCB-camera
\ Auswerte_Nr \ 2,
Vision system for the 2nd working area
\ Kanal-Nummer \ 1,
all cameras of 2nd gantry on connector >channel< 1/
3
\ *** Nachschwingzeit *** \ 50,
waiting time (in msec. until oscillating of the gantry stopped) before start to
read out the CCD Sensor of PCB-camera
\ ** Korrekturfaktor_A_X ** \ 17,
to calculate the pixel size by matirix math. calibrated with SITEST
\ ** Korrekturfaktor_B_X ** \ -11571,
to calculate the pixel size by matirix math. calibrated with SITEST
\ ** Korrekturfaktor_C_X ** \ 0,
by standard 0
\ ** Korrekturfaktor_A_Y ** \ 16,
to calculate the pixel size by matirix math. calibrated with SITEST
\ ** Korrekturfaktor_B_Y ** \ 11546,
to calculate the pixel size by matirix math. calibrated with SITEST
\ ** Korrekturfaktor_C_Y ** \ 0,
by standard 0
\ ** Kamera_Offset_X ** \ -191,
PCB-camera -comp.-camera-offset calibrated with Segment 1 at Segment
Offset bottom
\ ** Kamera_Offset_Y ** \ 100833,
PCB-camera -comp.-camera-offset calibrated with Segment 1 at Segment
Offset bottom
\ ** Kamera_Offset_Z ** \ 0,
The camera do not have an Angle Offset, here always 0.(each camera
have an mounting angle)
Edition 1.0 2 KAMDAT_MA_e.xls KAMDAT.MA SD EA1 S GC Training
\ ** Kamera_Offset_Winkel ** \ 8,
PCB camera mounting angle on the gantry. calibrated with SITEST
\ XU_Pixel \ 11571,
Pixel size in X direction in nm. calibrated with SITEST
\ YU_Pixel \ 11546]
Pixel size in Y direction in nm. calibrated with SITEST
\ Kamerabeschreibung 7. Kamera \
\ Sensorsystem_Individuum_Nr \ 3012,
3. mean gantry 3 12 is Type nr. of the Standard-component-camer
a
\ Auswerte_Nr \ 2,
Vision system for the 2nd working area
\ Kanal-Nummer \ 4,
all cameras of 3rd gantry on connector >channel< 2/4
\ *** Nachschwingzeit *** \ 0,
waiting time valid only for PCB-camera
\ ** Korrekturfaktor_A_X ** \ -11,
to calculate the pixel size by matirix math. calibrated with SITEST
\ ** Korrekturfaktor_B_X ** \ 49370,
to calculate the pixel size by matirix math. calibrated with SITEST
\ ** Korrekturfaktor_C_X ** \ 0,
by standard 0
\ ** Korrekturfaktor_A_Y ** \ 14,
to calculate the pixel size by matirix math. calibrated with SITEST
\ ** Korrekturfaktor_B_Y ** \ 49329,
to calculate the pixel size by matirix math. calibrated with SITEST
\ ** Korrekturfaktor_C_Y ** \ 0,
by standard 0
\ ** Kamera_Offset_X ** \ 0,
for PCB-camera -comp.-camera-offset is the comp. camera the reference
so here is always 0.
\ ** Kamera_Offset_Y ** \ 0,
for PCB-camera -comp.-camera-offset is the comp. camera the reference
so here is always 0.
\ ** Kamera_Offset_Z ** \ 0,
The camera do not have an Angle Offset, here always 0.(each camera
have an mounting angle)
\ ** Kamera_Offset_Winkel ** \ 1,
Component camera mounting angle to the turning level of the placement
STAR. calibrated with SITEST
\ XU_Pixel \ 49370,
Pixel size in X direction in nm. calibrated with SITEST
\ YU_Pixel \ 49329]
Pixel size in Y direction in nm. calibrated with SITEST
\ Kamerabeschreibung 8. Kamera \
\ Sensorsystem_Individuum_Nr \ 2012,
2. mean gantry 2 12 is Type nr. of the Standard-component-camer
a
\ Auswerte_Nr \ 2,
Vision system for the 2nd working area
\ Kanal-Nummer \ 3,
all cameras of 2nd gantry on connector >channel< 1/
3
\ *** Nachschwingzeit *** \ 0,
waiting time valid only for PCB-camera
\ ** Korrekturfaktor_A_X ** \ -199,
to calculate the pixel size by matirix math. calibrated with SITEST
\ ** Korrekturfaktor_B_X ** \ 49123,
to calculate the pixel size by matirix math. calibrated with SITEST
\ ** Korrekturfaktor_C_X ** \ 0,
by standard 0
\ ** Korrekturfaktor_A_Y ** \ 204,
to calculate the pixel size by matirix math. calibrated with SITEST
\ ** Korrekturfaktor_B_Y ** \ 49141,
to calculate the pixel size by matirix math. calibrated with SITEST
\ ** Korrekturfaktor_C_Y ** \ 0,
by standard 0
\ ** Kamera_Offset_X ** \ 0,
for PCB-camera -comp.-camera-offset is the comp. camera the reference
so here is always 0.
\ ** Kamera_Offset_Y ** \ 0,
for PCB-camera -comp.-camera-offset is the comp. camera the reference
so here is always 0.
\ ** Kamera_Offset_Z ** \ 0,
The camera do not have an Angle Offset, here always 0.(each camera
have an mounting angle)
\ ** Kamera_Offset_Winkel ** \ -56,
Component camera mounting angle to the turning level of the placement
STAR. calibrated with SITEST
\ XU_Pixel \ 49123,
Pixel size in X direction in nm. calibrated with SITEST
\ YU_Pixel \ 49141
Pixel size in Y direction in nm. calibrated with SITEST
}
Edition 1.0 3 KAMDAT_MA_e.xls KAMDAT.MA SD EA1 S GC Training
