\ ## File converted by makonv at Wed Nov 21 13:37:20 2001 \
{
\ Datei \ "PIP_OFF.MA"|
same format as in 501.XX and 502.XX SW-Version
\ Version \ "31.503.011119_E"|
\ Maschinentyp \ "HS50"|
\ *** Pipetten-Versatz *** \
\ Pipetten-Offsets Kopf 1 \
For placement head gantry 1 for S25HMX / HS5X. only 6 values for HM with 6 n.head.
\ Pipetten-Offsets Segment 1 \
Segment Offset1 (top) is the Offset of sleeve turning axis to RV-comp.ca.center point
\ ** Offset_x ** \ 17,
values in µ
m
\ ** Offset_y ** \ -8,
Limit for Segment Offset top is 120 µm Relatively between the calibration values of all
segments of a placement head. Absolutely No segment override the limit 450 µm
\ ** Offset_w ** \ 0]
on the sleeve is the 0 degree 180 degree position identical in the reader head. So no angle
offset could be measured.
\ Pipetten-Offsets Segment 2 \
\ ** Offset_x ** \ 42,
turning axis segment 2 to component camera cente
r
\ ** Offset_y ** \ -6,
turning axis segment 2 to component camera cente
r
\ ** Offset_w ** \ 0]
\ Pipetten-Offsets Segment 3 \
\ ** Offset_x ** \ 22,
\ ** Offset_y ** \ 3,
\ ** Offset_w ** \ 0]
\ Pipetten-Offsets Segment 4 \
\ ** Offset_x ** \ 22,
\ ** Offset_y ** \ 8,
\ ** Offset_w ** \ 0]
\ Pipetten-Offsets Segment 5 \
\ ** Offset_x ** \ 12,
\ ** Offset_y ** \ 29,
\ ** Offset_w ** \ 0]
\ Pipetten-Offsets Segment 6 \
\ ** Offset_x ** \ -1,
\ ** Offset_y ** \ 33,
\ ** Offset_w ** \ 0]
\ Pipetten-Offsets Segment 7 \
\ ** Offset_x ** \ 29,
\ ** Offset_y ** \ 34,
\ ** Offset_w ** \ 0]
\ Pipetten-Offsets Segment 8 \
\ ** Offset_x ** \ 11,
\ ** Offset_y ** \ 37,
\ ** Offset_w ** \ 0]
\ Pipetten-Offsets Segment 9 \
\ ** Offset_x ** \ 33,
\ ** Offset_y ** \ 21,
\ ** Offset_w ** \ 0]
\ Pipetten-Offsets Segment 10 \
\ ** Offset_x ** \ 22,
\ ** Offset_y ** \ 19,
\ ** Offset_w ** \ 0]
\ Pipetten-Offsets Segment 11 \
\ ** Offset_x ** \ 31,
\ ** Offset_y ** \ 26,
\ ** Offset_w ** \ 0]
\ Pipetten-Offsets Segment 12 \
\ ** Offset_x ** \ 37,
\ ** Offset_y ** \ 10,
\ ** Offset_w ** \ 0>
\ Pipetten-Offsets Kopf 2 \
for placement head on gantry 2 for S25 HMX and HS5
X
\ Pipetten-Offsets Segment 1 \
\ ** Offset_x ** \ 51,
\ ** Offset_y ** \ -24,
\ ** Offset_w ** \ 0]
\ Pipetten-Offsets Segment 2 \
\ ** Offset_x ** \ 44,
\ ** Offset_y ** \ -7,
\ ** Offset_w ** \ 0]
\ Pipetten-Offsets Segment 3 \
\ ** Offset_x ** \ 60,
Edition 1.0 1 PIP_OFF_MA_e.xls PIP_OFF.MA SD EA1 S GC Training
\ ** Offset_y ** \ -24,
\ ** Offset_w ** \ 0]
\ Pipetten-Offsets Segment 4 \
\ ** Offset_x ** \ 41,
\ ** Offset_y ** \ -12,
\ ** Offset_w ** \ 0]
\ Pipetten-Offsets Segment 5 \
\ ** Offset_x ** \ 60,
\ ** Offset_y ** \ 9,
\ ** Offset_w ** \ 0]
\ Pipetten-Offsets Segment 6 \
\ ** Offset_x ** \ 30,
\ ** Offset_y ** \ -8,
\ ** Offset_w ** \ 0]
\ Pipetten-Offsets Segment 7 \
\ ** Offset_x ** \ 48,
\ ** Offset_y ** \ -23,
\ ** Offset_w ** \ 0]
\ Pipetten-Offsets Segment 8 \
\ ** Offset_x ** \ 62,
\ ** Offset_y ** \ -14,
\ ** Offset_w ** \ 0]
\ Pipetten-Offsets Segment 9 \
\ ** Offset_x ** \ 33,
\ ** Offset_y ** \ -8,
\ ** Offset_w ** \ 0]
\ Pipetten-Offsets Segment 10 \
\ ** Offset_x ** \ 6,
\ ** Offset_y ** \ -20,
\ ** Offset_w ** \ 0]
\ Pipetten-Offsets Segment 11 \
\ ** Offset_x ** \ 22,
\ ** Offset_y ** \ -27,
\ ** Offset_w ** \ 0]
\ Pipetten-Offsets Segment 12 \
\ ** Offset_x ** \ 32,
\ ** Offset_y ** \ -30,
\ ** Offset_w ** \ 0>
\ Pipetten-Offsets Kopf 3 \
for placement head on gantry 3 for HS5X 0 values for S25HMX
\ Pipetten-Offsets Segment 1 \
\ ** Offset_x ** \ 12,
\ ** Offset_y ** \ 13,
\ ** Offset_w ** \ 0]
\ Pipetten-Offsets Segment 2 \
\ ** Offset_x ** \ 2,
\ ** Offset_y ** \ -8,
\ ** Offset_w ** \ 0]
\ Pipetten-Offsets Segment 3 \
\ ** Offset_x ** \ 33,
\ ** Offset_y ** \ -18,
\ ** Offset_w ** \ 0]
\ Pipetten-Offsets Segment 4 \
\ ** Offset_x ** \ -6,
\ ** Offset_y ** \ -31,
\ ** Offset_w ** \ 0]
\ Pipetten-Offsets Segment 5 \
\ ** Offset_x ** \ 10,
\ ** Offset_y ** \ -13,
\ ** Offset_w ** \ 0]
\ Pipetten-Offsets Segment 6 \
\ ** Offset_x ** \ 7,
\ ** Offset_y ** \ -28,
\ ** Offset_w ** \ 0]
\ Pipetten-Offsets Segment 7 \
\ ** Offset_x ** \ 5,
\ ** Offset_y ** \ -10,
\ ** Offset_w ** \ 0]
\ Pipetten-Offsets Segment 8 \
Edition 1.0 2 PIP_OFF_MA_e.xls PIP_OFF.MA SD EA1 S GC Training
